AMD Ryzen 7 7800X3D Benchmark, Test and specs

Last updated:
The AMD Ryzen 7 7800X3D is a 8 core processor. It can handle 16 threads simultaneously and was introduced in Q1/2023. The AMD Ryzen 7 7800X3D is based on the 6. generation of the AMD Ryzen 7 series and requires a mainboard with the socket AM5 (LGA 1718). The AMD Ryzen 7 7800X3D scores 2,137 points with one CPU core in the Geekbench 5 benchmark. When using all CPU cores, the result is 13,620 points.
AMD Ryzen 7 7800X3D

CPU lineage

Here you can see which group the AMD Ryzen 7 7800X3D belongs to and which processor is the predecessor of the AMD Ryzen 7 7800X3D.

Name: AMD Ryzen 7 7800X3D
Family: AMD Ryzen 7 (63)
CPU group: AMD Ryzen 7000 (14)
Architecture: Raphael (Zen 4)
Segment: Desktop / Server
Generation: 6
Predecessor: AMD Ryzen 7 5800X3D
Successor: --

CPU Cores and Base Frequency

The 8 CPU cores of the AMD Ryzen 7 7800X3D clock with 4.20 GHz (5.00 GHz). The number of CPU cores and the clock frequency of the processor are largely responsible for the overall performance.

CPU Cores / Threads: 8 / 16
Core architecture: normal
Cores: 8x Zen 4
Hyperthreading / SMT: Yes
Overclocking: No
Frequency: 4.20 GHz
Turbo Frequency (1 Core): 5.00 GHz
Turbo Frequency (8 Cores): 4.60 GHz

Internal Graphics

With the AMD Radeon Graphics (Raphael), the AMD Ryzen 7 7800X3D has an build in graphic solution. It has 2 SM processors, which have a total of 128 texture shaders. The iGPU not only enables games, but also significantly accelerates video playback.

GPU name: AMD Radeon Graphics (Raphael)
GPU frequency: 0.40 GHz
GPU (Turbo): 2.20 GHz
Compute units: 2
Shader: 128
Hardware Raytracing: No
Release date: Q3/2022
Max. displays: 3
Generation: 9
Direct X: 12
Technology: 5 nm
Max. GPU Memory: 8 GB
Frame Generation: No

Hardware codec support

Processors that have an integrated graphics can play videos faster and more efficiently. This can have a positive effect on the battery life of notebooks, for example.

h265 / HEVC (8 bit): Decode / Encode
h265 / HEVC (10 bit): Decode / Encode
h264: Decode / Encode
VP8: Decode / Encode
VP9: Decode / Encode
AV1: No
AVC: Decode / Encode
VC-1: Decode
JPEG: Decode / Encode

Memory & PCIe

The AMD Ryzen 7 7800X3D supports up to 128 GB memory in up to 2 (Dual Channel) memory channels. This results in a maximum memory bandwidth of 83.2 GB/s.

Memory type: Memory bandwidth:
DDR5-5200
83.2 GB/s
Max. Memory: 128 GB
Memory channels: 2 (Dual Channel)
ECC: Yes
PCIe: 5.0 x 24
PCIe Bandwidth: 94.5 GB/s

Thermal Management

With the TDP, the processor manufacturer specifies the cooling solution required for the processor. The AMD Ryzen 7 7800X3D has a TDP of 120 W.

TDP (PL1 / PBP): 120 W
TDP (PL2): 162 W
TDP up: --
TDP down: --
Tjunction max.: 89 °C

Technical details

The AMD Ryzen 7 7800X3D has a 104.00 MB large cache. The processor is manufactured in 5 nm. Modern production increases the efficiency of the processor.

Technology: 5 nm
Chip design: Chiplet
Socket: AM5 (LGA 1718)
L2-Cache: 8.00 MB
L3-Cache: 96.00 MB
AES-NI: Yes
Operating systems: Windows 10, Windows 11, Linux
Virtualization: AMD-V, SVM
Instruction set (ISA): x86-64 (64 bit)
ISA extensions: SSE4a, SSE4.1, SSE4.2,FMA3, AVX2, AVX512
Release date: Q1/2023
Release price: --
Part Number: 100-100000910WOF
Documents: Technical data sheet

Rate this processor

Here you can rate this processor to help other visitors make their purchase decision. The average rating of this processor is 4.1 stars (28 ratings). Rate now:

Benchmark results

Verified Benchmark results
The benchmark results for the AMD Ryzen 7 7800X3D have been carefully checked by us. We only publish benchmark results that have been created by us or that have been submitted by a visitor and then checked by a team member. All results are based on and fullfill our benchmark guidelines.


Cinebench 2024 (Single-Core)

The Cinebench 2024 benchmark is based on the Redshift rendering engine, which is also used in Maxon's 3D program Cinema 4D. The benchmark runs are each 10 minutes long to test whether the processor is limited by its heat generation.
Intel Core i7-13700T Intel Core i7-13700T
16C 24T @ 4.90 GHz
110
AMD Ryzen 7 7700 AMD Ryzen 7 7700
8C 16T @ 5.30 GHz
108
Intel Core i5-14500HX Intel Core i5-14500HX
14C 20T @ 4.90 GHz
108
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 5.00 GHz
107
AMD Ryzen 7 7745HX AMD Ryzen 7 7745HX
8C 16T @ 5.10 GHz
107
Intel Core i7-12700F Intel Core i7-12700F
12C 20T @ 4.90 GHz
107
Intel Core i7-12700 Intel Core i7-12700
12C 20T @ 4.90 GHz
107

Cinebench 2024 (Multi-Core)

The Multi-Core test of the Cinebench 2024 benchmark uses all cpu cores to render using the Redshift rendering engine, which is also used in Maxons Cinema 4D. The benchmark run is 10 minutes long to test whether the processor is limited by its heat generation.
Intel Core i7-12700K Intel Core i7-12700K
12C 20T @ 5.00 GHz
1175
Intel Core i7-12700KF Intel Core i7-12700KF
12C 20T @ 5.00 GHz
1175
Intel Xeon W-2295 Intel Xeon W-2295
18C 36T @ 4.80 GHz
1124
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 5.00 GHz
1115
Intel Core i7-13700T Intel Core i7-13700T
16C 24T @ 4.90 GHz
1095
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
1087
AMD Ryzen 9 3900XT AMD Ryzen 9 3900XT
12C 24T @ 4.70 GHz
1074

Cinebench R23 (Single-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.
AMD Ryzen 5 7500F AMD Ryzen 5 7500F
6C 12T @ 5.00 GHz
1827
Intel Core i7-1360P Intel Core i7-1360P
12C 16T @ 5.00 GHz
1822
Intel Core i7-1355U Intel Core i7-1355U
10C 12T @ 5.00 GHz
1819
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 5.00 GHz
1811
AMD Ryzen 7 8840U AMD Ryzen 7 8840U
8C 16T @ 5.10 GHz
1807
AMD Ryzen Z1 Extreme AMD Ryzen Z1 Extreme
8C 16T @ 5.10 GHz
1807
Intel Core i7-12700HL Intel Core i7-12700HL
14C 20T @ 4.70 GHz
1806

Cinebench R23 (Multi-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.
AMD Ryzen 7 7745HX AMD Ryzen 7 7745HX
8C 16T @ 3.60 GHz
18065
AMD Ryzen 7 8700G AMD Ryzen 7 8700G
8C 16T @ 4.70 GHz
18040
Intel Xeon E5-2683 v3 Intel Xeon E5-2683 v3
14C 28T @ 2.50 GHz
17896
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 4.60 GHz
17762
Intel Core i5-12600KF Intel Core i5-12600KF
10C 16T @ 4.50 GHz
17660
Intel Core i5-12600K Intel Core i5-12600K
10C 16T @ 4.50 GHz
17660
AMD EPYC 7351 AMD EPYC 7351
16C 32T @ 2.90 GHz
17401

Geekbench 5, 64bit (Single-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.
Intel Core i9-13900K Intel Core i9-13900K
24C 32T @ 5.80 GHz
2147
Apple A17 Pro Apple A17 Pro
6C 6T @ 3.78 GHz
2140
AMD Ryzen 9 7945HX3D AMD Ryzen 9 7945HX3D
16C 32T @ 5.40 GHz
2138
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 5.00 GHz
2137
AMD Ryzen 9 7945HX AMD Ryzen 9 7945HX
16C 32T @ 5.40 GHz
2130
Intel Core i9-13900F Intel Core i9-13900F
24C 32T @ 5.60 GHz
2130
Intel Core i9-13900 Intel Core i9-13900
24C 32T @ 5.60 GHz
2130

Geekbench 5, 64bit (Multi-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.
Intel Core Ultra 9 185H Intel Core Ultra 9 185H
16C 22T @ 4.50 GHz
13796
Intel Core i9-12900TE Intel Core i9-12900TE
16C 24T @ 3.00 GHz
13738
Intel Core i5-13500HX Intel Core i5-13500HX
14C 20T @ 4.10 GHz
13650
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 4.60 GHz
13620
Intel Xeon Gold 5218R Intel Xeon Gold 5218R
20C 40T @ 2.30 GHz
13548
Intel Xeon E5-2699 v4 Intel Xeon E5-2699 v4
22C 44T @ 2.80 GHz
13547
Intel Core i5-13600 Intel Core i5-13600
14C 20T @ 4.40 GHz
13534

Geekbench 6 (Single-Core)

Geekbench 6 is a benchmark for modern computers, notebooks and smartphones. What is new is an optimized utilization of newer CPU architectures, e.g. based on the big.LITTLE concept and combining CPU cores of different sizes. The single-core benchmark only evaluates the performance of the fastest CPU core, the number of CPU cores in a processor is irrelevant here.
AMD Ryzen 7 7700 AMD Ryzen 7 7700
8C 16T @ 5.30 GHz
2769
AMD Ryzen 7 PRO 7745 AMD Ryzen 7 PRO 7745
8C 16T @ 5.30 GHz
2769
Intel Core i9-13950HX Intel Core i9-13950HX
24C 32T @ 5.50 GHz
2745
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 5.00 GHz
2731
Intel Core i7-14700T Intel Core i7-14700T
20C 28T @ 5.20 GHz
2723
AMD Ryzen 7 8700G AMD Ryzen 7 8700G
8C 16T @ 5.10 GHz
2720
AMD Ryzen Threadripper PRO 7995WX AMD Ryzen Threadripper PRO 7995WX
96C 192T @ 5.10 GHz
2714

Geekbench 6 (Multi-Core)

Geekbench 6 is a benchmark for modern computers, notebooks and smartphones. What is new is an optimized utilization of newer CPU architectures, e.g. based on the big.LITTLE concept and combining CPU cores of different sizes. The multi-core benchmark evaluates the performance of all of the processor's CPU cores. Virtual thread improvements such as AMD SMT or Intel's Hyper-Threading have a positive impact on the benchmark result.
Intel Core i7-14650HX Intel Core i7-14650HX
16C 24T @ 2.20 GHz
14420
AMD EPYC 7542 AMD EPYC 7542
32C 64T @ 3.20 GHz
14416
AMD Ryzen 7 8700G AMD Ryzen 7 8700G
8C 16T @ 4.70 GHz
14326
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 4.60 GHz
14229
Apple M2 Max (30-GPU) Apple M2 Max (30-GPU)
12C 12T @ 3.50 GHz
14207
Apple M2 Max (38-GPU) Apple M2 Max (38-GPU)
12C 12T @ 3.50 GHz
14207
Apple M2 Pro (12-CPU 19-GPU) Apple M2 Pro (12-CPU 19-GPU)
12C 12T @ 3.50 GHz
14207

iGPU - FP32 Performance (Single-precision GFLOPS)

The theoretical computing performance of the internal graphics unit of the processor with simple accuracy (32 bit) in GFLOPS. GFLOPS indicates how many billion floating point operations the iGPU can perform per second.
Apple A12 Bionic Apple A12 Bionic
Apple A12 @ 1.13 GHz
576
MediaTek Dimensity 820 MediaTek Dimensity 820
ARM Mali-G57 MP5 @ 0.90 GHz
576
Qualcomm Snapdragon 835 Qualcomm Snapdragon 835
Qualcomm Adreno 540 @ 0.71 GHz
567
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
AMD Ryzen 5 PRO 7645 AMD Ryzen 5 PRO 7645
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
AMD Ryzen 7 PRO 7745 AMD Ryzen 7 PRO 7745
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
AMD Ryzen 9 PRO 7945 AMD Ryzen 9 PRO 7945
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563

Estimated results for PassMark CPU Mark

Some of the CPUs listed below have been benchmarked by CPU-monkey. However the majority of CPUs have not been tested and the results have been estimated by a CPU-monkey’s secret proprietary formula. As such they do not accurately reflect the actual Passmark CPU mark values and are not endorsed by PassMark Software Pty Ltd.
AMD Ryzen 7 7700 AMD Ryzen 7 7700
8C 16T @ 4.60 GHz
35640
Intel Xeon Gold 6326 Intel Xeon Gold 6326
16C 32T @ 3.30 GHz
35245
Intel Xeon Platinum 8180 Intel Xeon Platinum 8180
28C 56T @ 2.80 GHz
35217
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 4.60 GHz
35060
Intel Xeon Gold 6242R Intel Xeon Gold 6242R
20C 40T @ 3.30 GHz
34982
Intel Core i7-12700KF Intel Core i7-12700KF
12C 20T @ 4.70 GHz
34688
Intel Core i7-12700K Intel Core i7-12700K
12C 20T @ 4.70 GHz
34688

CPU performance per watt (efficiency)

Efficiency of the processor under full load in the Cinebench R23 (multi-core) benchmark. The benchmark result is divided by the average energy required (CPU package power in watts). The higher the value, the more efficient the CPU is under full load.
Intel Core i9-13900H Intel Core i9-13900H
18,760 CB R23 MC @ 87 W
216
AMD Ryzen 7 7700 AMD Ryzen 7 7700
19,540 CB R23 MC @ 92 W
212
AMD Ryzen 5 8600G AMD Ryzen 5 8600G
14,067 CB R23 MC @ 68 W
207
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
17,762 CB R23 MC @ 87 W
205
AMD Ryzen 7 5700U AMD Ryzen 7 5700U
9,555 CB R23 MC @ 47 W
204
Intel Core i5-1135G7 Intel Core i5-1135G7
5,642 CB R23 MC @ 28 W
202
Intel Core i5-1335U Intel Core i5-1335U
8,970 CB R23 MC @ 45 W
199

Benchmarks


Description of the processor

The AMD Ryzen 7 7800X3D is the successor to the AMD Ryzen 7 5800X3D, which is popular with gamers. Like its predecessor, the AMD Ryzen 7 7800X3D can also use a significantly larger level 3 cache. Instead of 32 MB level 3 cache (AMD Ryzen 7 7700X), the AMD Ryzen 7 7800X3D has a full 96 MB level 3 cache.

In synthetic benchmarks like Cinebench R23 or Geekbench 5, the larger cache doesnt matter. In games, however, the AMD Ryzen 7 7800X3D can place itself well ahead of the normal Ryzen 7 processors. The advantage increases at high frame rates and low resolutions.

All other technical data are similar to those of the normal Ryzen 7000 processors. The AMD Ryzen 7 7800X3D comes with 8 CPU cores that can process 16 threads in parallel. It is overclockable and can increase its clock frequency in turbo mode (AMD PBO2) up to 5.0 GHz. The base clock is 4.2 GHz. The core architecture "Zen 4" is also state-of-the-art.

Like all other AMD Ryzen 7000 desktop processors, the AMD Ryzen 7 7800X3D also comes with a small integrated graphics (iGPU). Specifically, an AMD Radeon Graphics with only 2 execution units is installed here, which is primarily used for graphics output. The iGPU is not fast enough for gaming.

Up to 128 GB of DDR5-5200 RAM can be installed, with the so-called sweet spot of the Ryzen 7000 processors being slightly faster DDR5-5600 or DDR5-6000 modules. These can be automatically overclocked with the AMD EXPO profile, provided the modules support this.

External devices such as a dedicated graphics card can be connected via PCIe 5.0. This also applies to fast M.2 SSDs that can be connected with PCIe 5.0 or PCIe 4.0.

The TDP of the AMD Ryzen 7 7800X3D is 120 watts, whereby the processor can consume up to 170 watts, provided the cooling and temperature of the processor allow it.
