CPU lineageThe segment in which we have classified the Intel Core i5-13500. Here you can see if it is a desktop processor or a mobile processor or which processor may be the successor of the Intel Core i5-13500. |
|
Name: | Intel Core i5-13500 |
Family: | Intel Core i5 |
CPU group: | Intel Core i 13000 |
Segment: | Desktop / Server |
Generation: | 13 |
Predecessor: | Intel Core i5-12500 |
Successor: | -- |
CPU Cores / Threads: | 14 / 20 |
Core architecture: | hybrid (big.LITTLE) |
A-Core: | 6x Golden Cove |
B-Core: | 8x Gracemont |
Hyperthreading / SMT: | Yes |
Overclocking: | No |
A-Core Frequency: | 2.50 GHz (4.80 GHz) |
B-Core Frequency: | 1.80 GHz (3.50 GHz) |
GPU name: | Intel UHD Graphics 770 |
GPU frequency: | 0.30 GHz |
GPU (Turbo): | 1.55 GHz |
Execution units: | 32 |
Shader: | 256 |
Max. GPU Memory: | 64 GB |
Max. displays: | 3 |
Generation: | 11 |
Direct X: | 12 |
Technology: | 10 nm |
Release date: | Q4/2021 |
h265 / HEVC (8 bit): | Decode / Encode |
h265 / HEVC (10 bit): | Decode / Encode |
h264: | Decode / Encode |
VP8: | Decode / Encode |
VP9: | Decode / Encode |
AV1: | Decode |
AVC: | Decode / Encode |
VC-1: | Decode |
JPEG: | Decode / Encode |
Memory & PCIeThe memory type as well as the amount of memory can greatly affect the speed of the processor. The memory bandwidth depends on several factors and is given in gigabytes per second. |
|
Memory type: | DDR4-3200 DDR5-4800 |
Max. Memory: | 128 GB |
Memory channels: | 2 (Dual Channel) |
Bandwidth: | 89.6 GB/s |
ECC: | Yes |
PCIe: | 5.0 x 20 |
AES-NI: | Yes |
Thermal ManagementThe Thermal Design Power (TDP for short) specifies the necessary cooling solution to cool the processor sufficiently. The TDP usually only gives a rough idea of the real consumption of a CPU. |
|
TDP (PL1 / PBP): | 65 W |
TDP (PL2): | 154 W |
TDP up: | -- |
TDP down: | -- |
Tjunction max.: | 100 °C |
Technology: | 10 nm |
Chip design: | Monolithic |
Socket: | LGA 1700 |
L2-Cache: | 11.50 MB |
L3-Cache: | 24.00 MB |
Architecture: | Alder Lake S Refresh |
Operating systems: | Windows 10, Windows 11, Linux |
Virtualization: | VT-x, VT-x EPT, VT-d |
Instruction set (ISA): | x86-64 (64 bit) |
ISA extensions: | SSE4.1, SSE4.2, AVX2, AVX2+ |
Release date: | Q1/2023 |
Release price: | 232 $ |
Part Number: | -- |
Documents: | Technical data sheet |
![]() |
