AMD Ryzen 7 7700X Benchmark, Test and specs

Last updated:
The AMD Ryzen 7 7700X is a 8 core processor. It can handle 16 threads simultaneously and was introduced in Q4/2022. The AMD Ryzen 7 7700X is based on the 6. generation of the AMD Ryzen 7 series and requires a mainboard with the socket AM5 (LGA 1718). The AMD Ryzen 7 7700X scores 2,202 points with one CPU core in the Geekbench 5 benchmark. When using all CPU cores, the result is 14,487 points.
AMD Ryzen 7 7700X

At a glance

Name: AMD Ryzen 7 7700X
Family: AMD Ryzen 7 (70)
CPU group: AMD Ryzen 7000 (14)
Architecture: Raphael (Zen 4)
Technology: 5 nm
Segment: Desktop / Server
Generation: 6
Predecessor: AMD Ryzen 7 5700X
Successor: AMD Ryzen 7 9700X

CPU Cores and Base Frequency

The 8 CPU cores of the AMD Ryzen 7 7700X clock with 4.50 GHz (5.40 GHz). The number of CPU cores and the clock frequency of the processor are largely responsible for the overall performance.

CPU Cores / Threads: 8 / 16
Core architecture: normal
Cores: 8x
Hyperthreading / SMT: Yes
Overclocking: Yes
Frequency: 4.50 GHz
Turbo Frequency (1 Core): 5.40 GHz
Turbo Frequency (8 Cores): 5.20 GHz

Integrated graphics (iGPU)

With the AMD Radeon Graphics (Raphael), the AMD Ryzen 7 7700X has an build in graphic solution. It has 2 SM processors, which have a total of 128 texture shaders. The iGPU not only enables games, but also significantly accelerates video playback.

GPU name: AMD Radeon Graphics (Raphael)
GPU frequency: 0.40 GHz
GPU (Turbo): 2.20 GHz
Compute units: 2
Shader: 128
Hardware Raytracing: No
Release date: Q3/2022
Max. displays: 3
Generation: 9
Direct X: 12
Technology: 5 nm
Max. GPU Memory: 8 GB
Frame Generation: No

Hardware codec support

Processors that have an integrated graphics can play videos faster and more efficiently. This can have a positive effect on the battery life of notebooks, for example.

h265 / HEVC (8 bit): Decode / Encode
h265 / HEVC (10 bit): Decode / Encode
h264: Decode / Encode
VP8: Decode / Encode
VP9: Decode / Encode
AV1: Decode
AVC: Decode / Encode
VC-1: Decode
JPEG: Decode / Encode

Memory & PCIe

The AMD Ryzen 7 7700X supports up to 128 GB memory in up to 2 (Dual Channel) memory channels. This results in a maximum memory bandwidth of 83.2 GB/s.

Memory type: Memory bandwidth:
DDR5-5200
83.2 GB/s
Max. Memory: 128 GB
Memory channels: 2 (Dual Channel)
ECC: Yes
PCIe: 5.0 x 24
PCIe Bandwidth: 94.5 GB/s

Thermal Management

With the TDP, the processor manufacturer specifies the cooling solution required for the processor. The AMD Ryzen 7 7700X has a TDP of 105 W.

TDP (PL1 / PBP): 105 W
TDP (PL2): 142 W
TDP up: --
TDP down: --
Tjunction max.: 95 °C

Technical details

The AMD Ryzen 7 7700X has a 40.00 MB large cache. The processor is manufactured in 5 nm. Modern production increases the efficiency of the processor.

Technology: 5 nm
Chip design: Chiplet
Socket: AM5 (LGA 1718)
L2-Cache: 8.00 MB
L3-Cache: 32.00 MB
AES-NI: Yes
Operating systems: Windows 10, Windows 11, Linux
Virtualization: AMD-V, SVM
Instruction set (ISA): x86-64 (64 bit)
ISA extensions: SSE4a, SSE4.1, SSE4.2,FMA3, AVX2, AVX512
Release date: Q4/2022
Release price: 399 $
Part Number: 100-100000591WOF
Documents: Technical data sheet

Rate this processor

Here you can rate this processor to help other visitors make their purchase decision. The average rating of this processor is 4.5 stars (31 ratings). Rate now:

Benchmark results

Verified Benchmark results
The benchmark results for the AMD Ryzen 7 7700X have been carefully checked by us. We only publish benchmark results that have been created by us or that have been submitted by a visitor and then checked by a team member. All results are based on and fullfill our benchmark guidelines.

Screenshots:

Cinebench 2024 (Single-Core)

The Cinebench 2024 benchmark is based on the Redshift rendering engine, which is also used in Maxon's 3D program Cinema 4D. The benchmark runs are each 10 minutes long to test whether the processor is limited by its heat generation.
Intel Core i9-13900 Intel Core i9-13900
24C 32T @ 5.60 GHz
121
Apple M2 Apple M2
8C 8T @ 3.50 GHz
120
Apple M2 (8-GPU) Apple M2 (8-GPU)
8C 8T @ 3.50 GHz
120
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
119
AMD Ryzen Threadripper 7970X AMD Ryzen Threadripper 7970X
32C 64T @ 5.30 GHz
119
Intel Core i7-13700F Intel Core i7-13700F
16C 24T @ 5.20 GHz
118
Intel Core i7-13700 Intel Core i7-13700
16C 24T @ 5.20 GHz
118

Cinebench 2024 (Multi-Core)

The Multi-Core test of the Cinebench 2024 benchmark uses all cpu cores to render using the Redshift rendering engine, which is also used in Maxons Cinema 4D. The benchmark run is 10 minutes long to test whether the processor is limited by its heat generation.
Intel Xeon W-2295 Intel Xeon W-2295
18C 36T @ 4.80 GHz
1124
AMD Ryzen 7 7800X3D AMD Ryzen 7 7800X3D
8C 16T @ 5.00 GHz
1115
Intel Core i7-13700T Intel Core i7-13700T
16C 24T @ 4.90 GHz
1095
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
1087
Qualcomm Snapdragon X Elite (X1E-78-100) Qualcomm Snapdragon X Elite (X1E-78-100)
12C 12T @ 3.40 GHz
1080
AMD Ryzen 9 3900XT AMD Ryzen 9 3900XT
12C 24T @ 4.70 GHz
1074
Intel Core Ultra 9 185H Intel Core Ultra 9 185H
16C 22T @ 5.10 GHz
1070

Cinebench R23 (Single-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.
Intel Core i5-13600K Intel Core i5-13600K
14C 20T @ 5.10 GHz
2021
Intel Core i5-13600KF Intel Core i5-13600KF
14C 20T @ 5.10 GHz
2021
Intel Core i9-13900H Intel Core i9-13900H
14C 20T @ 5.40 GHz
2016
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
2010
Intel Core i9-12900KF Intel Core i9-12900KF
16C 24T @ 5.20 GHz
1997
Intel Core i9-12900K Intel Core i9-12900K
16C 24T @ 5.20 GHz
1997
AMD Ryzen Threadripper 7970X AMD Ryzen Threadripper 7970X
32C 64T @ 5.30 GHz
1988

Cinebench R23 (Multi-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.
Intel Core i7-13650HX Intel Core i7-13650HX
14C 20T @ 4.40 GHz
20999
Apple M3 Max (14-CPU 30-GPU) Apple M3 Max (14-CPU 30-GPU)
14C 14T @ 3.60 GHz
20983
AMD Ryzen 9 5900 AMD Ryzen 9 5900
12C 24T @ 4.10 GHz
20955
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.20 GHz
20399
Intel Core i9-12950HX Intel Core i9-12950HX
16C 24T @ 2.30 GHz
19655
AMD Ryzen 7 PRO 7745 AMD Ryzen 7 PRO 7745
8C 16T @ 4.60 GHz
19540
AMD Ryzen 7 7700 AMD Ryzen 7 7700
8C 16T @ 4.60 GHz
19540

Geekbench 5, 64bit (Single-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.
AMD Ryzen 9 7900 AMD Ryzen 9 7900
12C 24T @ 5.40 GHz
2206
Intel Core i7-14700K Intel Core i7-14700K
20C 28T @ 5.60 GHz
2204
Intel Core i7-14700KF Intel Core i7-14700KF
20C 28T @ 5.60 GHz
2204
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
2202
Intel Core i9-14900F Intel Core i9-14900F
24C 32T @ 5.80 GHz
2202
Intel Core i9-14900 Intel Core i9-14900
24C 32T @ 5.80 GHz
2202
AMD Ryzen 5 7600X AMD Ryzen 5 7600X
6C 12T @ 5.30 GHz
2197

Geekbench 5, 64bit (Multi-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.
Intel Xeon Gold 6230 Intel Xeon Gold 6230
20C 40T @ 2.50 GHz
14529
Intel Xeon W-2275 Intel Xeon W-2275
14C 28T @ 4.00 GHz
14528
AMD Ryzen 9 5900X AMD Ryzen 9 5900X
12C 24T @ 4.50 GHz
14515
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.20 GHz
14487
AMD EPYC 7F52 AMD EPYC 7F52
16C 32T @ 3.70 GHz
14477
AMD Ryzen 9 3950X AMD Ryzen 9 3950X
16C 32T @ 4.00 GHz
14322
Intel Core i9-9960X Intel Core i9-9960X
16C 32T @ 4.10 GHz
14314

Geekbench 6 (Single-Core)

Geekbench 6 is a benchmark for modern computers, notebooks and smartphones. What is new is an optimized utilization of newer CPU architectures, e.g. based on the big.LITTLE concept and combining CPU cores of different sizes. The single-core benchmark only evaluates the performance of the fastest CPU core, the number of CPU cores in a processor is irrelevant here.
AMD Ryzen AI 9 HX 370 AMD Ryzen AI 9 HX 370
12C 24T @ 5.10 GHz
2913
Intel Xeon w7-2495X Intel Xeon w7-2495X
24C 48T @ 4.80 GHz
2913
AMD Ryzen 9 7950X3D AMD Ryzen 9 7950X3D
16C 32T @ 5.70 GHz
2906
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
2898
Intel Core i7-14700KF Intel Core i7-14700KF
20C 28T @ 5.60 GHz
2898
Intel Core i7-14700K Intel Core i7-14700K
20C 28T @ 5.60 GHz
2898
AMD Ryzen Threadripper 7980X AMD Ryzen Threadripper 7980X
64C 128T @ 5.10 GHz
2897

Geekbench 6 (Multi-Core)

Geekbench 6 is a benchmark for modern computers, notebooks and smartphones. What is new is an optimized utilization of newer CPU architectures, e.g. based on the big.LITTLE concept and combining CPU cores of different sizes. The multi-core benchmark evaluates the performance of all of the processor's CPU cores. Virtual thread improvements such as AMD SMT or Intel's Hyper-Threading have a positive impact on the benchmark result.
Intel Core i5-14600T Intel Core i5-14600T
14C 20T @ 1.80 GHz
15354
AMD Ryzen Threadripper PRO 3975WX AMD Ryzen Threadripper PRO 3975WX
32C 64T @ 3.75 GHz
15273
AMD EPYC 7313 AMD EPYC 7313
16C 32T @ 3.40 GHz
15264
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.20 GHz
15137
Qualcomm Snapdragon X Elite (X1E-00-1DE) Qualcomm Snapdragon X Elite (X1E-00-1DE)
12C 12T @ 3.80 GHz
15068
AMD Ryzen AI 9 HX 370 AMD Ryzen AI 9 HX 370
12C 24T @ 2.00 GHz
15044
Intel Core i7-13700T Intel Core i7-13700T
16C 24T @ 4.20 GHz
15020

Cinebench R20 (Single-Core)

Cinebench R20 is the successor of Cinebench R15 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.
Intel Core i9-12900K Intel Core i9-12900K
16C 24T @ 5.20 GHz
779
Intel Core i5-13600K Intel Core i5-13600K
14C 20T @ 5.10 GHz
775
Intel Core i5-13600KF Intel Core i5-13600KF
14C 20T @ 5.10 GHz
775
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
773
AMD Ryzen Threadripper 7970X AMD Ryzen Threadripper 7970X
32C 64T @ 5.30 GHz
773
AMD Ryzen 9 PRO 7945 AMD Ryzen 9 PRO 7945
12C 24T @ 5.40 GHz
764
AMD Ryzen 9 7900 AMD Ryzen 9 7900
12C 24T @ 5.40 GHz
764

Cinebench R20 (Multi-Core)

Cinebench R20 is the successor of Cinebench R15 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.
AMD Ryzen 9 5900X AMD Ryzen 9 5900X
12C 24T @ 4.50 GHz
8491
Intel Core i7-13700HX Intel Core i7-13700HX
16C 24T @ 4.20 GHz
8342
Intel Core i5-13500 Intel Core i5-13500
14C 20T @ 4.20 GHz
8076
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.20 GHz
7944
AMD Ryzen 7 PRO 7745 AMD Ryzen 7 PRO 7745
8C 16T @ 4.60 GHz
7845
AMD Ryzen 7 7700 AMD Ryzen 7 7700
8C 16T @ 4.60 GHz
7739
Intel Core i9-7980XE Intel Core i9-7980XE
18C 36T @ 3.50 GHz
7671

iGPU - FP32 Performance (Single-precision GFLOPS)

The theoretical computing performance of the internal graphics unit of the processor with simple accuracy (32 bit) in GFLOPS. GFLOPS indicates how many billion floating point operations the iGPU can perform per second.
Apple A12 Bionic Apple A12 Bionic
Apple A12 @ 1.13 GHz
576
MediaTek Dimensity 820 MediaTek Dimensity 820
ARM Mali-G57 MP5 @ 0.90 GHz
576
Qualcomm Snapdragon 835 Qualcomm Snapdragon 835
Qualcomm Adreno 540 @ 0.71 GHz
567
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
AMD Ryzen 5 9600X AMD Ryzen 5 9600X
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
AMD Ryzen 7 9700X AMD Ryzen 7 9700X
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
AMD Ryzen 9 9900X AMD Ryzen 9 9900X
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563

Blender 3.1 Benchmark

In the Blender Benchmark 3.1, the scenes "monster", "junkshop" and "classroom" are rendered and the time required by the system is measured. In our benchmark we test the CPU and not the graphics card. Blender 3.1 was presented as a standalone version in March 2022.
Intel Core i7-12700K Intel Core i7-12700K
12C 20T @ 4.70 GHz
319
Intel Core i7-12700KF Intel Core i7-12700KF
12C 20T @ 4.70 GHz
319
AMD Ryzen 9 5900X AMD Ryzen 9 5900X
12C 24T @ 4.50 GHz
308
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.20 GHz
306
Intel Core i5-13500 Intel Core i5-13500
14C 20T @ 4.20 GHz
286
Intel Core i7-12700F Intel Core i7-12700F
12C 20T @ 4.00 GHz
284
Intel Core i7-12700 Intel Core i7-12700
12C 20T @ 4.00 GHz
284

Estimated results for PassMark CPU Mark

Some of the CPUs listed below have been benchmarked by CPU-monkey. However the majority of CPUs have not been tested and the results have been estimated by a CPU-monkey’s secret proprietary formula. As such they do not accurately reflect the actual Passmark CPU mark values and are not endorsed by PassMark Software Pty Ltd.
Intel Xeon W-3175X Intel Xeon W-3175X
28C 56T @ 3.80 GHz
37183
Intel Core i9-12900 Intel Core i9-12900
16C 24T @ 4.20 GHz
36739
Intel Core i9-12900F Intel Core i9-12900F
16C 24T @ 4.20 GHz
36739
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.20 GHz
36536
Intel Core i9-13900E Intel Core i9-13900E
24C 32T @ 4.20 GHz
36455
Intel Core i9-12950HX Intel Core i9-12950HX
16C 24T @ 2.30 GHz
36411
Intel Core i9-12900HX Intel Core i9-12900HX
16C 24T @ 2.30 GHz
35642

CPU-Z Benchmark 17 (Single-Core)

The CPU-Z benchmark measures a processor's performance by measuring the time it takes the system to complete all benchmark calculations. The faster the benchmark is completed, the higher the score.
Intel Core i7-12700K Intel Core i7-12700K
12C 20T @ 5.00 GHz
790
Intel Core i7-12700KF Intel Core i7-12700KF
12C 20T @ 5.00 GHz
787
Intel Core i5-13500 Intel Core i5-13500
14C 20T @ 4.80 GHz
780
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
774
Intel Core Ultra 9 185H Intel Core Ultra 9 185H
16C 22T @ 5.10 GHz
767
AMD Ryzen 5 7600X AMD Ryzen 5 7600X
6C 12T @ 5.30 GHz
767
Intel Core i5-12600KF Intel Core i5-12600KF
10C 16T @ 4.90 GHz
766

CPU-Z Benchmark 17 (Multi-Core)

The CPU-Z benchmark measures a processor's performance by measuring the time it takes the system to complete all benchmark calculations. The faster the benchmark is completed, the higher the score.
Intel Core i5-13600 Intel Core i5-13600
14C 20T @ 2.70 GHz
8835
Intel Core i5-13500 Intel Core i5-13500
14C 20T @ 2.50 GHz
8727
AMD Ryzen Threadripper 1950X AMD Ryzen Threadripper 1950X
16C 32T @ 3.40 GHz
8719
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 4.50 GHz
8381
AMD Ryzen 9 3900X AMD Ryzen 9 3900X
12C 24T @ 3.80 GHz
8183
AMD Ryzen 9 3900XT AMD Ryzen 9 3900XT
12C 24T @ 4.10 GHz
8118
Intel Core Ultra 9 185H Intel Core Ultra 9 185H
16C 22T @ 2.30 GHz
8097

Cinebench R15 (Single-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.
Intel Core i9-13900K Intel Core i9-13900K
24C 32T @ 5.80 GHz
330
Intel Core i9-13900KF Intel Core i9-13900KF
24C 32T @ 5.80 GHz
330
AMD Ryzen 9 7900X AMD Ryzen 9 7900X
12C 24T @ 5.60 GHz
325
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
322
AMD Ryzen 9 PRO 7945 AMD Ryzen 9 PRO 7945
12C 24T @ 5.40 GHz
314
AMD Ryzen 9 7900 AMD Ryzen 9 7900
12C 24T @ 5.40 GHz
314
AMD Ryzen 5 7600X AMD Ryzen 5 7600X
6C 12T @ 5.30 GHz
313

Cinebench R15 (Multi-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.
Intel Xeon Platinum 8160T Intel Xeon Platinum 8160T
24C 48T @ 2.60 GHz
3444
Intel Xeon W-2295 Intel Xeon W-2295
18C 36T @ 3.80 GHz
3422
Apple M3 Max (16-CPU 40-GPU) Apple M3 Max (16-CPU 40-GPU)
16C 16T @ 3.60 GHz
3375
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.20 GHz
3328
Intel Core i7-12700KF Intel Core i7-12700KF
12C 20T @ 4.70 GHz
3327
Intel Core i7-12700K Intel Core i7-12700K
12C 20T @ 4.70 GHz
3327
Intel Xeon Gold 6148F Intel Xeon Gold 6148F
20C 40T @ 3.00 GHz
3310

CPU performance per watt (efficiency)

Efficiency of the processor under full load in the Cinebench R23 (multi-core) benchmark. The benchmark result is divided by the average energy required (CPU package power in watts). The higher the value, the more efficient the CPU is under full load.
Intel Core i5-1135G7 Intel Core i5-1135G7
5,642 CB R23 MC @ 28 W
202
Intel Core i5-1335U Intel Core i5-1335U
8,970 CB R23 MC @ 45 W
199
AMD Ryzen 9 7950X AMD Ryzen 9 7950X
38,657 CB R23 MC @ 197 W
196
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
20,399 CB R23 MC @ 104 W
196
Intel Core i9-13900HX Intel Core i9-13900HX
30,320 CB R23 MC @ 158 W
192
Intel Core i7-13650HX Intel Core i7-13650HX
20,999 CB R23 MC @ 110 W
191
Intel Core i9-13980HX Intel Core i9-13980HX
31,572 CB R23 MC @ 168 W
188

Benchmarks


News and articles for the AMD Ryzen 7 7700X

Why the new AMD Ryzen 7000 processors for the AM5 socket are currently not a good deal
Why the new AMD Ryzen 7000 processors for the AM5 socket are currently not a good deal
Posted by Stefan on 2022-10-11
At the end of September 2022, the time had come: AMD presented its latest desktop processors called AMD Ryzen 7000. Initially, 4 processors with 6 to 16 CPU cores were released.

The new socket AM5 (LGA 1718) is used for the first time, which is intended to replace the very durable socket AM4 introduced in 2017 as AMDs mainstream platform. This includes (depending on the chipset) PCIe 5.0 support as well as the exclusive use of DDR5 memory on all AM5 mainboards.

Officially, DDR5-5200 is the maximum, but with AMDs EXPO Technology which is similar to Intel's XMP 3.0, AMD now also has a solution for easy overclocking of the main memory. AMD itself names DDR5-6000 as the sweet spot for the new AMD Ryzen 7000 processors.
The evolution of AMD Ryzen processors
The evolution of AMD Ryzen processors
Posted by Stefan on 2022-09-06
The AMD Ryzen processors are designed for the mid to high-end range and are grouped into the Ryzen 3, Ryzen 5, Ryzen 7 and Ryzen 9 classes. AMD follows the market leader Intel, which groups its Core i series (Intel Core i3, Core i5, Core i7 and Core i9) identically.

The AMD Ryzen processors were first introduced by AMD in Q1 2017. They are the successor to the not particularly successful AMD Bulldozer processors. The latter were manufactured using an outdated manufacturing process and could not keep up with the competing products from Intel. AMD lost a large portion of its desktop processor market share during this period.
AMD Ryzen 7000 and Intel Core i 13 Gen at almost 6 GHz clock speed
AMD Ryzen 7000 and Intel Core i 13 Gen at almost 6 GHz clock speed
Posted by Stefan on 2022-08-29
In September, both AMD and Intel are introducing their new mainstream desktop processors. It doesn't seem to have been as close as this year for a long time, leaked benchmarks of the new top models from AMD and Intel point to a head-to-head race.

This year even the 6 GHz clock limit is almost within reach. With a good cooler and some overclocking it should be possible to reach the 6 GHz limit. But even in series production, the manufacturers try to realize the highest possible clock frequency, at least on one core.

Description of the processor

The AMD Ryzen 7 7700X is an eight-core processor from AMD for the desktop. Its 8 CPU cores support simultaneous multi-threading and can run two threads per core at the same time. A maximum of 16 threads are available in total. Thats enough for fast computer games or professional applications like image or video editing or CAD software.

The base clock frequency of the AMD Ryzen 7 7700X is already high at 4.5 GHz. This can be increased to up to 5.4 GHz (load on one core) via the turbo mode. The processor has to operate in a defined temperature range so that the maximum possible turbo clock can be used. If the temperatures are too high, the clock frequency is automatically reduced.

The processor can be freely overclocked. Since both the power consumption and the temperature development are significantly higher when overclocked, a sufficiently dimensioned cooler for the processor is recommended.

The AMD Ryzen 7 7700X Raphael / Zen 4 CPU architecture supports DDR5-5200 type RAM with a maximum memory capacity of 128 GB. A maximum memory bandwidth of up to 83.2 GB/s is achieved using two memory channels (dual-channel operation).

External devices such as a dedicated graphics card can be connected to the computer via the PCIe 5.0 interface (maximum 16+4 = 20 lines). The TDP of the AMD Ryzen 7 7700X is 105 watts, but over a short period of time the maximum energy that the processor can consume can be up to 142 watts.

The processor has 8 MB level 2 and 32 MB level 3 cache. The AMD Ryzen 7 7700X is manufactured in an optimized 5 nm process at TSMC. The AMD Ryzen 7 7700X was introduced by AMD in the 3rd quarter of 2022 and fits into the AM5 socket, which replaces AMDs AM4 socket, which has been in use for many years.



Popular comparisons

1. AMD Ryzen 7 7700X Intel Core i7-13700K AMD Ryzen 7 7700X vs Intel Core i7-13700K
2. AMD Ryzen 9 5900X AMD Ryzen 7 7700X AMD Ryzen 9 5900X vs AMD Ryzen 7 7700X
3. AMD Ryzen 7 7700X AMD Ryzen 7 7800X3D AMD Ryzen 7 7700X vs AMD Ryzen 7 7800X3D
4. AMD Ryzen 7 7700X Intel Core i5-13600K AMD Ryzen 7 7700X vs Intel Core i5-13600K
5. AMD Ryzen 7 7700 AMD Ryzen 7 7700X AMD Ryzen 7 7700 vs AMD Ryzen 7 7700X
6. AMD Ryzen 7 5800X3D AMD Ryzen 7 7700X AMD Ryzen 7 5800X3D vs AMD Ryzen 7 7700X
7. AMD Ryzen 7 7700X AMD Ryzen 5 7600X AMD Ryzen 7 7700X vs AMD Ryzen 5 7600X
8. AMD Ryzen 7 7700X AMD Ryzen 7 5800X AMD Ryzen 7 7700X vs AMD Ryzen 7 5800X
9. AMD Ryzen 7 7700X AMD Ryzen 7 5700X AMD Ryzen 7 7700X vs AMD Ryzen 7 5700X
10. AMD Ryzen 7 7700X Intel Core i7-12700K AMD Ryzen 7 7700X vs Intel Core i7-12700K


back to index
