AMD Ryzen 9 7950X Benchmark, Test and specs

Last updated:
The AMD Ryzen 9 7950X has 16 cores with 32 threads and is based on the 6. gen of the AMD Ryzen 9 series. The processor uses a mainboard with the AM5 socket and was released in Q4/2022.
AMD Ryzen 9 7950X

CPU lineage

The segment in which we have classified the AMD Ryzen 9 7950X. Here you can see if it is a desktop processor or a mobile processor or which processor may be the successor of the AMD Ryzen 9 7950X.

Name: AMD Ryzen 9 7950X
Family: AMD Ryzen 9
CPU group: AMD Ryzen 7000
Segment: Desktop / Server
Generation: 6
Predecessor: AMD Ryzen 9 5950X
Successor: --

CPU Cores and Base Frequency

In addition to the number of CPU cores and threads, you can see here whether the AMD Ryzen 9 7950X can be overclocked. You will also find the clock frequencies of the processor (single-core and multi-core) here. The number of CPU cores greatly affects the speed of the processor.

CPU Cores / Threads: 16 / 32
Core architecture: normal
Cores: 16x
Hyperthreading / SMT: Yes
Overclocking: Yes
Frequency: 4.50 GHz
Turbo Frequency (1 Core): 5.70 GHz
Turbo Frequency (16 Cores): 5.20 GHz

Internal Graphics

The AMD Ryzen 9 7950X has integrated graphics, called iGPU for short. The iGPU uses the system's main memory as graphics memory and sits on the processor's die. A processor with integrated graphics is also called APU (Accelerated Processing Unit).

GPU name: AMD Radeon Graphics (Raphael)
GPU frequency: 0.40 GHz
GPU (Turbo): 2.20 GHz
Execution units: 2
Shader: 128
Max. GPU Memory: 8 GB
Max. displays: 3
Generation: 9
Direct X: 12
Technology: 5 nm
Release date: Q3/2022

Hardware codec support

A photo or video codec that is accelerated in hardware can greatly accelerate the working speed of a processor and extend the battery life of notebooks or smartphones when playing videos.

h265 / HEVC (8 bit): Decode / Encode
h265 / HEVC (10 bit): Decode / Encode
h264: Decode / Encode
VP8: Decode / Encode
VP9: Decode / Encode
AV1: No
AVC: Decode / Encode
VC-1: Decode
JPEG: Decode / Encode

Memory & PCIe

The memory type as well as the amount of memory can greatly affect the speed of the processor. The memory bandwidth depends on several factors and is given in gigabytes per second.

Memory type: DDR5-5200
Max. Memory: 128 GB
Memory channels: 2
Bandwidth: 83.2 GB/s
ECC: Yes
PCIe: 5.0 x 20
AES-NI: Yes

Thermal Management

The Thermal Design Power (TDP for short) specifies the necessary cooling solution to cool the processor sufficiently. The TDP usually only gives a rough idea of the real consumption of a CPU.

TDP (PL1): 170 W
TDP (PL2): 230 W
TDP up: --
TDP down: --
Tjunction max.: 95 °C

Technical details

Here you will find information on the size of the level 2 and level 3 cache of the AMD Ryzen 9 7950X as well as a list of the processors ISA extensions. We have documented the architecture and the manufacturing technology for you as well as the release date.

Technology: 5 nm
Chip design: Chiplet
Socket: AM5
L2-Cache: 16.00 MB
L3-Cache: 64.00 MB
Architecture: Raphael (Zen 4)
Operating systems: Windows 10, Windows 11, Linux
Virtualization: AMD-V, SVM
Instruction set (ISA): x86-64 (64 bit)
ISA extensions: SSE4a, SSE4.1, SSE4.2,FMA3, AVX2, AVX512
Release date: Q4/2022
Release price: 699 $
Part Number: 100-100000514WOF
Documents: Technical data sheet

Benchmark results

Verified Benchmark results
The benchmark results for the AMD Ryzen 9 7950X have been carefully checked by us. We only publish benchmark results that have been created by us or that have been submitted by a visitor and then checked by a team member. All results are based on and fullfill our benchmark guidelines.

Screenshots:

Cinebench R23 (Single-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

Intel Core i7-13700 Intel Core i7-13700
16C 24T @ 5.20 GHzNot verified
2107
Intel Core i7-13700F Intel Core i7-13700F
16C 24T @ 5.20 GHzNot verified
2107
Intel Core i9-12900KS Intel Core i9-12900KS
16C 24T @ 5.50 GHz
2082
AMD Ryzen 9 7950X AMD Ryzen 9 7950X
16C 32T @ 5.70 GHz
2072
AMD Ryzen 9 7900X AMD Ryzen 9 7900X
12C 24T @ 5.60 GHz
2041
Intel Core i5-13600KF Intel Core i5-13600KF
14C 20T @ 5.10 GHzNot verified
2029
Intel Core i5-13600K Intel Core i5-13600K
14C 20T @ 5.10 GHzNot verified
2029
Show all Cinebench R23 (Single-Core) results



Cinebench R23 (Multi-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

AMD Ryzen Threadripper 3970X AMD Ryzen Threadripper 3970X
32C 64T @ 3.80 GHz
44502
AMD Ryzen Threadripper PRO 3975WX AMD Ryzen Threadripper PRO 3975WX
32C 64T @ 3.75 GHz
42986
AMD Ryzen Threadripper PRO 5965WX AMD Ryzen Threadripper PRO 5965WX
24C 48T @ 4.00 GHz
40535
AMD Ryzen 9 7950X AMD Ryzen 9 7950X
16C 32T @ 5.20 GHz
38657
Intel Core i9-13900KF Intel Core i9-13900KF
24C 32T @ 5.50 GHzNot verified
38460
Intel Core i9-13900K Intel Core i9-13900K
24C 32T @ 5.50 GHzNot verified
38460
AMD Epyc 7502P AMD Epyc 7502P
32C 64T @ 3.00 GHz
36403
Show all Cinebench R23 (Multi-Core) results



Cinebench R20 (Single-Core)

Cinebench R20 is the successor of Cinebench R15 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

Intel Core i9-13900 Intel Core i9-13900
24C 32T @ 5.60 GHzNot verified
872
Intel Core i9-13900F Intel Core i9-13900F
24C 32T @ 5.60 GHzNot verified
872
Intel Core i9-12900KS Intel Core i9-12900KS
16C 24T @ 5.50 GHz
795
AMD Ryzen 9 7950X AMD Ryzen 9 7950X
16C 32T @ 5.70 GHz
793
AMD Ryzen 9 7900X AMD Ryzen 9 7900X
12C 24T @ 5.60 GHz
781
Intel Core i9-12900KF Intel Core i9-12900KF
16C 24T @ 5.20 GHz
779
Intel Core i9-12900K Intel Core i9-12900K
16C 24T @ 5.20 GHz
779
Show all Cinebench R20 (Single-Core) results



Cinebench R20 (Multi-Core)

Cinebench R20 is the successor of Cinebench R15 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

AMD Epyc 7662 AMD Epyc 7662
64C 128T @ 2.40 GHz
18203
AMD Ryzen Threadripper 3970X AMD Ryzen Threadripper 3970X
32C 64T @ 3.80 GHz
17105
AMD Ryzen Threadripper PRO 3975WX AMD Ryzen Threadripper PRO 3975WX
32C 64T @ 3.75 GHz
16740
AMD Ryzen 9 7950X AMD Ryzen 9 7950X
16C 32T @ 5.20 GHz
15120
Intel Core i9-13900KF Intel Core i9-13900KF
24C 32T @ 5.50 GHzNot verified
14960
Intel Core i9-13900K Intel Core i9-13900K
24C 32T @ 5.50 GHzNot verified
14960
AMD Ryzen Threadripper 3960X AMD Ryzen Threadripper 3960X
24C 48T @ 4.00 GHz
13552
Show all Cinebench R20 (Multi-Core) results



Geekbench 5, 64bit (Single-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

AMD Ryzen 9 7950X AMD Ryzen 9 7950X
16C 32T @ 5.70 GHz
2242
AMD Ryzen 9 7900X AMD Ryzen 9 7900X
12C 24T @ 5.60 GHz
2226
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
2202
AMD Ryzen 5 7600X AMD Ryzen 5 7600X
6C 12T @ 5.30 GHz
2197
Intel Core i9-13900KF Intel Core i9-13900KF
24C 32T @ 5.80 GHzNot verified
2147
Intel Core i9-13900K Intel Core i9-13900K
24C 32T @ 5.80 GHzNot verified
2147
Intel Core i9-13900F Intel Core i9-13900F
24C 32T @ 5.60 GHzNot verified
2130
Show all Geekbench 5, 64bit (Single-Core) results



Geekbench 5, 64bit (Multi-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

AMD Epyc 7443P AMD Epyc 7443P
24C 48T @ 3.60 GHz
25985
AMD Ryzen Threadripper PRO 3975WX AMD Ryzen Threadripper PRO 3975WX
32C 64T @ 3.75 GHz
25211
AMD Epyc 7413 AMD Epyc 7413
24C 48T @ 3.40 GHz
24322
AMD Ryzen 9 7950X AMD Ryzen 9 7950X
16C 32T @ 5.20 GHz
24121
Apple M1 Ultra (48-GPU) Apple M1 Ultra (48-GPU)
20C 20T @ 3.20 GHz
24055
Apple M1 Ultra (64-GPU) Apple M1 Ultra (64-GPU)
20C 20T @ 3.20 GHz
24055
Intel Core i9-13900KF Intel Core i9-13900KF
24C 32T @ 5.50 GHzNot verified
23982
Show all Geekbench 5, 64bit (Multi-Core) results



iGPU - FP32 Performance (Single-precision GFLOPS)

The theoretical computing performance of the internal graphics unit of the processor with simple accuracy (32 bit) in GFLOPS. GFLOPS indicates how many billion floating point operations the iGPU can perform per second.

Apple A12 Bionic Apple A12 Bionic
Apple A12 @ 1.13 GHz
576
MediaTek Dimensity 820 MediaTek Dimensity 820
ARM Mali-G57 MP5 @ 0.90 GHz
576
Qualcomm Snapdragon 835 Qualcomm Snapdragon 835
Qualcomm Adreno 540 @ 0.71 GHz
567
AMD Ryzen 9 7950X AMD Ryzen 9 7950X
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
AMD Ryzen 5 7600X AMD Ryzen 5 7600X
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
AMD Ryzen 9 7900X AMD Ryzen 9 7900X
AMD Radeon Graphics (Raphael) @ 2.20 GHz
563
Show all iGPU - FP32 Performance (Single-precision GFLOPS) results



Cinebench R15 (Single-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

AMD Ryzen 9 7950X AMD Ryzen 9 7950X
16C 32T @ 5.70 GHz
331
AMD Ryzen 9 7900X AMD Ryzen 9 7900X
12C 24T @ 5.60 GHz
325
AMD Ryzen 7 7700X AMD Ryzen 7 7700X
8C 16T @ 5.40 GHz
322
AMD Ryzen 5 7600X AMD Ryzen 5 7600X
6C 12T @ 5.30 GHz
313
Intel Core i9-12900KS Intel Core i9-12900KS
16C 24T @ 5.50 GHz
294
Intel Core i9-12900KF Intel Core i9-12900KF
16C 24T @ 5.20 GHz
294
Intel Core i9-12900K Intel Core i9-12900K
16C 24T @ 5.20 GHz
294
Show all Cinebench R15 (Single-Core) results



Cinebench R15 (Multi-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

AMD Ryzen Threadripper 3990X AMD Ryzen Threadripper 3990X
64C 128T @ 3.20 GHz
10542
AMD Ryzen Threadripper PRO 3975WX AMD Ryzen Threadripper PRO 3975WX
32C 64T @ 3.75 GHz
7575
AMD Ryzen Threadripper 3970X AMD Ryzen Threadripper 3970X
32C 64T @ 3.80 GHz
7398
AMD Ryzen 9 7950X AMD Ryzen 9 7950X
16C 32T @ 5.20 GHz
6382
AMD Ryzen Threadripper 3960X AMD Ryzen Threadripper 3960X
24C 48T @ 4.00 GHz
5933
Intel Xeon W-3175X Intel Xeon W-3175X
28C 56T @ 3.80 GHz
5514
AMD Ryzen Threadripper 2990WX AMD Ryzen Threadripper 2990WX
32C 64T @ 3.00 GHz
5189
Show all Cinebench R15 (Multi-Core) results



News and articles for the AMD Ryzen 9 7950X

The evolution of AMD Ryzen processors
Posted by Stefan on 2022-09-06
The AMD Ryzen processors are designed for the mid to high-end range and are grouped into the Ryzen 3, Ryzen 5, Ryzen 7 and Ryzen 9 classes. AMD follows the market leader Intel, which groups its Core i series (Intel Core i3, Core i5, Core i7 and Core i9) identically.

The AMD Ryzen processors were first introduced by AMD in Q1 2017. They are the successor to the not particularly successful AMD Bulldozer processors. The latter were manufactured using an outdated manufacturing process and could not keep up with the competing products from Intel. AMD lost a large portion of its desktop processor market share during this period.
AMD Ryzen 7000 and Intel Core i 13 Gen at almost 6 GHz clock speed
Posted by Stefan on 2022-08-29
In September, both AMD and Intel are introducing their new mainstream desktop processors. It doesn't seem to have been as close as this year for a long time, leaked benchmarks of the new top models from AMD and Intel point to a head-to-head race.

This year even the 6 GHz clock limit is almost within reach. With a good cooler and some overclocking it should be possible to reach the 6 GHz limit. But even in series production, the manufacturers try to realize the highest possible clock frequency, at least on one core.
AMD Ryzen 5 7600X and AMD Ryzen 7 7800X are coming in September
Posted by Stefan on 2022-06-20
After we published a performance assessment of the AMD Ryzen 9 7950X last week, the well-known AMD leaker Greymon55 has now posted more informations via Twitter.

He predicts the first four models of the new Zen 4 desktop generation, which AMD would like to present at the end of 2022. There is also an alleged release date of September 15, 2022.
AMD Ryzen 9 7950X - Cinebench R23 Benchmark projection
Posted by Stefan on 2022-06-10
We give you a preview of AMD's new Zen 4 desktop processors and calculate the performance of the AMD Ryzen 9 7950X top model for the new AM5 socket. The performance data and other technical details come directly from the press kit that AMD released as part of its Financial Analyst Day on June 9, 2022.

Up to 15 percent more single-core performance and 35 percent more multi-core performance of the 16-core model are realistic !

The AMD Ryzen 9 7950X is currently the largest desktop processor for the AM5 socket from AMD. It has 16 equally sized CPU cores and can process up to 32 threads in parallel thanks to the support of Simultaneous Multi-Threading (SMT). Its basic clock frequency is already high at 4.5 GHz. Up to 5.5 GHz (1 core) or 5.2 GHz (all cores) are possible in turbo mode.

The AMD Ryzen 9 7950X is based on AMDs "Raphael" (Zen 4) architecture, which bundles Zen 4 CPU cores with a small RDNA2 graphics card. Similar to Intels desktop processors, the graphics card is not very fast and is only intended to ensure that the processor can also be operated without a dedicated graphics card.

The AMD Ryzen 9 7950X supports up to 256 GB DDR5 RAM (max. DDR5-5200). However, the clock frequency of the main memory can still be increased by overclocking. The processor itself can also be overclocked.

The processor is fast with a memory bandwidth of 83.2 GB/s (DDR5-5200 in two memory channels). The new PCIe 5.0 standard is also supported. With PCIe 5.0, even the latest graphics cards can be connected to the system without any loss of speed.

AMD has increased the TDP of the AM5 processors: the AMD Ryzen 9 7950X can consume up to 170 watts, and even more is possible in the short term with 230 watts.

The AMD Ryzen 9 7950X is manufactured in a 5 nm process at TSMC. The processor has 64 MB level 3 cache and 8 MB level 2 cache.

The new Zen 4 CPU cores can be clocked significantly higher than their predecessors and require less energy for the same performance due to the improved production (5 nm vs 7 nm with the predecessor). Overall, however, the power consumption has increased. CPU coolers for socket AM4 should be compatible with the new socket AM5.


Leaderboards

In our leaderboards, we have clearly compiled the best processors for specific categories for you. The leaderboards are always up to date and are regularly updated by us. The best processors are selected according to popularity and speed in benchmarks as well as the price-performance ratio.


Popular comparisons

1. Intel Core i9-13900K AMD Ryzen 9 7950X Intel Core i9-13900K vs AMD Ryzen 9 7950X
2. AMD Ryzen 9 7950X AMD Ryzen 9 5950X AMD Ryzen 9 7950X vs AMD Ryzen 9 5950X
3. AMD Ryzen 9 7950X Intel Core i9-12900K AMD Ryzen 9 7950X vs Intel Core i9-12900K
4. AMD Ryzen 9 7950X AMD Ryzen 7 5800X3D AMD Ryzen 9 7950X vs AMD Ryzen 7 5800X3D
5. AMD Ryzen 9 7950X AMD Ryzen 9 3900X AMD Ryzen 9 7950X vs AMD Ryzen 9 3900X
6. AMD Ryzen 9 3950X AMD Ryzen 9 7950X AMD Ryzen 9 3950X vs AMD Ryzen 9 7950X
7. AMD Ryzen 9 7900X AMD Ryzen 9 7950X AMD Ryzen 9 7900X vs AMD Ryzen 9 7950X
8. Apple M1 Ultra (64-GPU) AMD Ryzen 9 7950X Apple M1 Ultra (64-GPU) vs AMD Ryzen 9 7950X
9. Intel Core i9-12900KS AMD Ryzen 9 7950X Intel Core i9-12900KS vs AMD Ryzen 9 7950X
10. AMD Ryzen 9 7950X AMD Ryzen Threadripper PRO 5995WX AMD Ryzen 9 7950X vs AMD Ryzen Threadripper PRO 5995WX
11. Apple M2 AMD Ryzen 9 7950X Apple M2 vs AMD Ryzen 9 7950X
12. AMD Ryzen 9 7950X AMD Ryzen 9 5900X AMD Ryzen 9 7950X vs AMD Ryzen 9 5900X
13. AMD Ryzen 9 7950X Apple M1 AMD Ryzen 9 7950X vs Apple M1
14. Intel Core i7-13700K AMD Ryzen 9 7950X Intel Core i7-13700K vs AMD Ryzen 9 7950X
15. AMD Ryzen 9 7950X Intel Core i7-12700K AMD Ryzen 9 7950X vs Intel Core i7-12700K


back to index
