AMD Ryzen 7 5700G - Benchmark, Test and specs

The AMD Ryzen 7 5700G has 8 cores with 16 threads and is based on the 4. gen of the AMD Ryzen 7 series. The processor uses a mainboard with the AM4 socket and was released in Q2/2021.
AMD Ryzen 7 5700G
CPU lineageCPU lineage
Name: AMD Ryzen 7 5700G
Family: AMD Ryzen 7
CPU group: AMD Ryzen 5000G
Segment: Desktop / Server
Generation: 4
Predecessor: AMD Ryzen 7 4700G
Successor: --
CPU Cores and Base FrequencyCPU Cores and Base Frequency
CPU Cores / Threads: 8 / 16
Core architecture: normal
Cores: 8x
Hyperthreading / SMT: Yes
Overclocking: Yes
Frequency: 3.80 GHz
Turbo Frequency (1 Core): 4.60 GHz
Turbo Frequency (8 Cores): 4.20 GHz
Internal GraphicsInternal Graphics
GPU name: AMD Radeon 8 Graphics (Renoir)
GPU frequency: 2.00 GHz
GPU (Turbo): No turbo
Execution units: 8
Shader: 512
Max. GPU Memory: 2 GB
Max. displays: 3
Generation: 9
Direct X: 12
Technology: 7 nm
Release date: Q1/2020
Hardware codec supportHardware codec support
h265 / HEVC (8 bit): Decode / Encode
h265 / HEVC (10 bit): Decode / Encode
h264: Decode / Encode
VP8: Decode / Encode
VP9: Decode / Encode
AV1: No
AVC: Decode / Encode
VC-1: Decode
JPEG: Decode / Encode
Memory & PCIeMemory & PCIe
Memory type: DDR4-3200
Max. Memory: 64 GB
Memory channels: 2
Bandwidth: 51.2 GB/s
ECC: No
PCIe: 3.0 x 24
AES-NI: Yes
Thermal ManagementThermal Management
TDP (PL1): 65 W
TDP (PL2): --
TDP up: --
TDP down: 45 W
Tjunction max.: 95 °C
Technical detailsTechnical details
Instruction set (ISA): x86-64 (64 bit)
ISA extensions: SSE4a, SSE4.1, SSE4.2, AVX2, FMA3
L2-Cache: 4.00 MB
L3-Cache: 16.00 MB
Architecture: Cezanne (Zen 3)
Technology: 7 nm
Virtualization: AMD-V, SVM
Socket: AM4
Release date: Q2/2021
Part Number: --

Benchmark results

Verified Benchmark results
The benchmark results for the AMD Ryzen 7 5700G have been carefully checked by us. We only publish benchmark results that have been created by us or that have been submitted by a visitor and then checked by a team member. All results are based on and fullfill our benchmark guidelines.

Screenshots:

Cinebench R23 (Single-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

AMD Ryzen Threadripper PRO 5975WX AMD Ryzen Threadripper PRO 5975WX
32C 64T @ 3.60 GHzNot verified
1532
AMD Ryzen 9 5980HX AMD Ryzen 9 5980HX
8C 16T @ 3.30 GHz
1524
AMD Ryzen 9 5980HS AMD Ryzen 9 5980HS
8C 16T @ 3.00 GHz
1521
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
1517
Intel Core i7-11850H Intel Core i7-11850H
8C 16T @ 2.50 GHz
1517
Intel Core i7-11370H Intel Core i7-11370H
4C 8T @ 3.30 GHz
1517
AMD Ryzen 7 PRO 5875U AMD Ryzen 7 PRO 5875U
8C 16T @ 2.00 GHz
1510
Show all Cinebench R23 (Single-Core) results



Cinebench R23 (Multi-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

AMD Ryzen 7 6800U AMD Ryzen 7 6800U
8C 16T @ 2.70 GHz
14228
AMD Ryzen 7 PRO 6850U AMD Ryzen 7 PRO 6850U
8C 16T @ 2.70 GHz
14228
AMD Ryzen 7 5800 AMD Ryzen 7 5800
8C 16T @ 3.40 GHzNot verified
14065
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
14041
AMD Ryzen 9 6900HS AMD Ryzen 9 6900HS
8C 16T @ 3.00 GHz
13977
Intel Core i9-11980HK Intel Core i9-11980HK
8C 16T @ 3.30 GHz
13977
AMD Ryzen 9 5900HS Creator Edition AMD Ryzen 9 5900HS Creator Edition
8C 16T @ 3.30 GHz
13875
Show all Cinebench R23 (Multi-Core) results



Cinebench R20 (Single-Core)

Cinebench R20 is the successor of Cinebench R15 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

Intel Core i7-11370H Intel Core i7-11370H
4C 8T @ 3.30 GHz
590
Intel Core i7-11700 Intel Core i7-11700
8C 16T @ 2.50 GHz
589
Intel Core i7-11700F Intel Core i7-11700F
8C 16T @ 2.50 GHz
589
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
588
AMD Ryzen 7 5700X AMD Ryzen 7 5700X
8C 16T @ 3.40 GHz
588
AMD Ryzen 7 PRO 6850H AMD Ryzen 7 PRO 6850H
8C 16T @ 3.20 GHz
587
AMD Ryzen 7 6800H AMD Ryzen 7 6800H
8C 16T @ 3.20 GHz
587
Show all Cinebench R20 (Single-Core) results



Cinebench R20 (Multi-Core)

Cinebench R20 is the successor of Cinebench R15 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

Intel Core i9-11950H Intel Core i9-11950H
8C 16T @ 2.60 GHz
5547
Intel Xeon W-11955M Intel Xeon W-11955M
8C 16T @ 2.60 GHz
5547
AMD Ryzen 9 6900HS AMD Ryzen 9 6900HS
8C 16T @ 3.00 GHz
5524
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
5517
AMD Ryzen 7 PRO 6850U AMD Ryzen 7 PRO 6850U
8C 16T @ 2.70 GHz
5486
AMD Ryzen 7 6800U AMD Ryzen 7 6800U
8C 16T @ 2.70 GHz
5486
AMD Ryzen 9 5900HS Creator Edition AMD Ryzen 9 5900HS Creator Edition
8C 16T @ 3.30 GHz
5474
Show all Cinebench R20 (Multi-Core) results



Cinebench R15 (Single-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

Intel Core i9-11900KB Intel Core i9-11900KB
8C 16T @ 3.30 GHz
256
AMD Ryzen 7 5700X AMD Ryzen 7 5700X
8C 16T @ 3.40 GHz
253
AMD Ryzen 9 6900HS AMD Ryzen 9 6900HS
8C 16T @ 3.00 GHz
252
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
250
AMD Ryzen 7 5800X3D AMD Ryzen 7 5800X3D
8C 16T @ 3.40 GHz
249
AMD Ryzen 9 5980HS AMD Ryzen 9 5980HS
8C 16T @ 3.00 GHz
247
Intel Core i5-11600KF Intel Core i5-11600KF
6C 12T @ 3.90 GHz
245
Show all Cinebench R15 (Single-Core) results



Cinebench R15 (Multi-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

Intel Core i9-10900X Intel Core i9-10900X
10C 20T @ 3.70 GHz
2358
Intel Core i7-10700K Intel Core i7-10700K
8C 16T @ 3.80 GHz
2344
Intel Core i7-10700KF Intel Core i7-10700KF
8C 16T @ 3.80 GHz
2344
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
2307
AMD Ryzen 7 5700X AMD Ryzen 7 5700X
8C 16T @ 3.40 GHz
2307
Intel Xeon E5-2697 v3 Intel Xeon E5-2697 v3
14C 28T @ 2.60 GHz
2306
Intel Xeon Gold 6130 Intel Xeon Gold 6130
16C 32T @ 2.10 GHz
2296
Show all Cinebench R15 (Multi-Core) results



Geekbench 5, 64bit (Single-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

AMD Ryzen 9 5980HX AMD Ryzen 9 5980HX
8C 16T @ 3.30 GHz
1614
Intel Core i7-1255U Intel Core i7-1255U
10C 12T @ 1.70 GHz
1603
Intel Core i9-11900H Intel Core i9-11900H
8C 16T @ 2.50 GHz
1599
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
1595
Intel Core i7-11375H Intel Core i7-11375H
4C 8T @ 3.30 GHz
1592
Apple A14 Bionic Apple A14 Bionic
6C 6T @ 3.00 GHz
1590
Intel Core i7-1270P Intel Core i7-1270P
12C 16T @ 2.20 GHz
1587
Show all Geekbench 5, 64bit (Single-Core) results



Geekbench 5, 64bit (Multi-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

AMD Ryzen 7 5700X AMD Ryzen 7 5700X
8C 16T @ 3.40 GHz
10179
Intel Core i7-12700E Intel Core i7-12700E
12C 20T @ 2.10 GHz
10170
Intel Core i7-1280P Intel Core i7-1280P
14C 20T @ 1.80 GHz
10126
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
10097
AMD Ryzen 9 6900HS AMD Ryzen 9 6900HS
8C 16T @ 3.00 GHz
10094
Apple M1 Pro (8-CPU) Apple M1 Pro (8-CPU)
8C 8T @ 3.20 GHz
9996
Intel Xeon D-2183IT Intel Xeon D-2183IT
16C 32T @ 2.20 GHz
9914
Show all Geekbench 5, 64bit (Multi-Core) results



V-Ray CPU-Render Benchmark

V-Ray is a 3D rendering software from the manufacturer Chaos for designers and artists. Unlike many other render engines, V-Ray is capable of so-called hybrid rendering, in which the CPU and GPU work together at the same time.

However, the CPU benchmark we used (CPU Render Mode) only uses the system's processor. The working memory used plays a major role in the V-Ray benchmark. For our benchmarks we use the fastest RAM standard approved by the manufacturer (without overclocking).

Due to the high compatibility of V-Ray (including Autodesk 3ds Max, Maya, Cinema 4D, SketchUp, Unreal Engine and Blender), it is a frequently used software. With V-Ray, for example, photorealistic images can be rendered that laypeople cannot distinguish from normal photos.

Intel Core i7-11700 Intel Core i7-11700
8C 16T @ 2.50 GHz
9910
Intel Core i7-11700F Intel Core i7-11700F
8C 16T @ 2.50 GHz
9910
Intel Core i7-11800H Intel Core i7-11800H
8C 16T @ 2.30 GHz
9850
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
9844
AMD Ryzen 7 5700X AMD Ryzen 7 5700X
8C 16T @ 3.40 GHz
9844
AMD Ryzen 9 5900HS Creator Edition AMD Ryzen 9 5900HS Creator Edition
8C 16T @ 3.30 GHz
9710
AMD Ryzen 9 5900HX AMD Ryzen 9 5900HX
8C 16T @ 3.30 GHz
9710
Show all V-Ray CPU-Render Benchmark results



iGPU - FP32 Performance (Single-precision GFLOPS)

The theoretical computing performance of the internal graphics unit of the processor with simple accuracy (32 bit) in GFLOPS. GFLOPS indicates how many billion floating point operations the iGPU can perform per second.

Intel Core i7-11370H Intel Core i7-11370H
Intel Iris Xe Graphics 96 (Tiger Lake G7) @ 1.35 GHz
2070
Intel Core i7-11375H Intel Core i7-11375H
Intel Iris Xe Graphics 96 (Tiger Lake G7) @ 1.35 GHz
2070
Intel Core i7-1185G7 Intel Core i7-1185G7
Intel Iris Xe Graphics 96 (Tiger Lake G7) @ 1.35 GHz
2070
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
AMD Radeon 8 Graphics (Renoir) @ 2.00 GHz
2048
AMD Ryzen 7 PRO 5875U AMD Ryzen 7 PRO 5875U
AMD Radeon 8 Graphics (Renoir) @ 2.00 GHz
2048
AMD Ryzen 7 5700GE AMD Ryzen 7 5700GE
AMD Radeon 8 Graphics (Renoir) @ 2.00 GHz
2048
AMD Ryzen 7 PRO 5750GE AMD Ryzen 7 PRO 5750GE
AMD Radeon 8 Graphics (Renoir) @ 2.00 GHz
2048
Show all iGPU - FP32 Performance (Single-precision GFLOPS) results



Blender 3.1 Benchmark

In the Blender Benchmark 3.1, the scenes "monster", "junkshop" and "classroom" are rendered and the time required by the system is measured. In our benchmark we test the CPU and not the graphics card. Blender 3.1 was presented as a standalone version in March 2022.

Intel Xeon E5-2680 v4 Intel Xeon E5-2680 v4
14C 28T @ 2.40 GHz
230
AMD Ryzen 7 5800X AMD Ryzen 7 5800X
8C 16T @ 3.80 GHz
225
AMD Ryzen Threadripper 2920X AMD Ryzen Threadripper 2920X
12C 24T @ 3.50 GHz
224
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
223
AMD Ryzen 7 PRO 5750G AMD Ryzen 7 PRO 5750G
8C 16T @ 3.80 GHz
223
Intel Core i7-11700KF Intel Core i7-11700KF
8C 16T @ 3.60 GHz
215
Intel Core i7-11700K Intel Core i7-11700K
8C 16T @ 3.60 GHz
215
Show all Blender 3.1 Benchmark results



Estimated results for PassMark CPU Mark

Some of the CPUs listed below have been benchmarked by CPU-monkey. However the majority of CPUs have not been tested and the results have been estimated by a CPU-monkey’s secret proprietary formula. As such they do not accurately reflect the actual Passmark CPU mark values and are not endorsed by PassMark Software Pty Ltd.

Intel Core i9-10900K Intel Core i9-10900K
10C 20T @ 3.70 GHz
24090
Intel Xeon Gold 6140 Intel Xeon Gold 6140
18C 36T @ 2.30 GHz
23965
Intel Xeon Gold 6132 Intel Xeon Gold 6132
14C 28T @ 2.60 GHz
23907
AMD Ryzen 7 5700G AMD Ryzen 7 5700G
8C 16T @ 3.80 GHz
23641
AMD Ryzen 7 4700 AMD Ryzen 7 4700
8C 16T @ 3.60 GHzNot verified
23554
AMD Ryzen 7 PRO 4750G AMD Ryzen 7 PRO 4750G
8C 16T @ 3.60 GHz
23554
AMD Ryzen 7 4700G AMD Ryzen 7 4700G
8C 16T @ 3.60 GHz
23554
Show all Estimated results for PassMark CPU Mark results



The AMD Ryzen 7 5700G is an 8-core processor from AMD. It is based on the AMD "Cezanne" APU architecture, which is mainly used in mobile devices and, unlike the normal AMD Ryzen desktop processors, has an internal graphics unit (iGPU). With the AMD "Cezanne" architecture, Zen 3 CPU cores with AMD Vega graphics are placed on one chip. This means that the level 3 cache is smaller, as the chip would otherwise become too big and expensive. However, the "Cezanne" APUs have a cache that is twice as large as their predecessors of the AMD "Renoir" architecture, specifically the AMD Ryzen 7 5700G now has 16 instead of 8 MB.

The AMD Ryzen 7 5700G can use its eight CPU cores with a clock rate of up to 4.5 GHz, provided that only one CPU core is used. If all CPU cores are loaded, 4.2 GHz are still possible. The base clock is quite a high 3.6 GHz. The AMD Ryzen 7 5700G makes it possible to build small, yet fast desktop systems, with the ASRock DeskMini case, for example, being the basis for the system.

The internal graphics of the AMD Ryzen 7 5700G are based on the previous design with slightly improved clock frequencies. The graphics achieve around 2.1 TFLOPs of FP32 tube performance and is sufficient to play moderately demanding games in Full HD (1080p) resolution. The AMD Vega 8 Graphics is also sufficient for video and photo editing. However, the new and free video codec AV1 is not yet accelerated via hardware. Both the new Apple M1 processor and the new Intel Tiger Lake with Intel XE graphics already play videos that have been created with the new AV1 codec via hardware. This improves energy efficiency and, in the case of mobile devices, also improves battery performance.

The AMD Ryzen 7 5700G is specified with a TDP of 65 watts. This is also possible thanks to the improved 7 nm production. AMD has its current processors manufactured by TSMC.


Leaderboards

In our leaderboards, we have clearly compiled the best processors for specific categories for you. The leaderboards are always up to date and are regularly updated by us. The best processors are selected according to popularity and speed in benchmarks as well as the price-performance ratio.


Popular comparisons

1. AMD Ryzen 7 5700G AMD Ryzen 7 5800X AMD Ryzen 7 5700G vs AMD Ryzen 7 5800X
2. AMD Ryzen 5 5600G AMD Ryzen 7 5700G AMD Ryzen 5 5600G vs AMD Ryzen 7 5700G
3. AMD Ryzen 7 5700G AMD Ryzen 5 5600X AMD Ryzen 7 5700G vs AMD Ryzen 5 5600X
4. AMD Ryzen 7 5700G AMD Ryzen 7 PRO 4750G AMD Ryzen 7 5700G vs AMD Ryzen 7 PRO 4750G
5. AMD Ryzen 7 3700X AMD Ryzen 7 5700G AMD Ryzen 7 3700X vs AMD Ryzen 7 5700G
6. Intel Core i7-11700 AMD Ryzen 7 5700G Intel Core i7-11700 vs AMD Ryzen 7 5700G
7. AMD Ryzen 7 PRO 5750G AMD Ryzen 7 5700G AMD Ryzen 7 PRO 5750G vs AMD Ryzen 7 5700G
8. AMD Ryzen 7 5700G AMD Ryzen 5 3400G AMD Ryzen 7 5700G vs AMD Ryzen 5 3400G
9. Intel Core i5-12600K AMD Ryzen 7 5700G Intel Core i5-12600K vs AMD Ryzen 7 5700G
10. AMD Ryzen 7 5700G AMD Ryzen 7 4700G AMD Ryzen 7 5700G vs AMD Ryzen 7 4700G
11. Intel Core i7-11700K AMD Ryzen 7 5700G Intel Core i7-11700K vs AMD Ryzen 7 5700G
12. Apple M1 AMD Ryzen 7 5700G Apple M1 vs AMD Ryzen 7 5700G
13. AMD Ryzen 7 5700G AMD Ryzen 5 3600 AMD Ryzen 7 5700G vs AMD Ryzen 5 3600
14. AMD Ryzen 7 5700G AMD Ryzen 9 5900HX AMD Ryzen 7 5700G vs AMD Ryzen 9 5900HX
15. AMD Ryzen 7 5700G AMD Ryzen 7 5700U AMD Ryzen 7 5700G vs AMD Ryzen 7 5700U
16. AMD Ryzen 7 5700G AMD Ryzen 5 PRO 4650G AMD Ryzen 7 5700G vs AMD Ryzen 5 PRO 4650G
17. AMD Ryzen 7 5700G AMD Ryzen 7 5800 AMD Ryzen 7 5700G vs AMD Ryzen 7 5800
18. AMD Ryzen 7 5700G AMD Ryzen 7 3800X AMD Ryzen 7 5700G vs AMD Ryzen 7 3800X
19. Intel Core i7-10700 AMD Ryzen 7 5700G Intel Core i7-10700 vs AMD Ryzen 7 5700G
20. Intel Core i7-12700K AMD Ryzen 7 5700G Intel Core i7-12700K vs AMD Ryzen 7 5700G
21. AMD Ryzen 7 5700G AMD Ryzen 7 5800H AMD Ryzen 7 5700G vs AMD Ryzen 7 5800H
22. AMD Ryzen 5 2400G AMD Ryzen 7 5700G AMD Ryzen 5 2400G vs AMD Ryzen 7 5700G
23. Intel Core i5-12400 AMD Ryzen 7 5700G Intel Core i5-12400 vs AMD Ryzen 7 5700G
24. AMD Ryzen 7 5700G AMD Ryzen 9 5900X AMD Ryzen 7 5700G vs AMD Ryzen 9 5900X
25. AMD Ryzen 7 5700G AMD Ryzen 7 2700X AMD Ryzen 7 5700G vs AMD Ryzen 7 2700X


back to index
