CPU lineageThe segment in which we have classified the Intel Core i5-12500H. Here you can see if it is a desktop processor or a mobile processor or which processor may be the successor of the Intel Core i5-12500H. |
|
Name: | Intel Core i5-12500H |
Family: | Intel Core i5 |
CPU group: | Intel Core i 12000H |
Segment: | Mobile |
Generation: | 12 |
Predecessor: | Intel Core i5-11500H |
Successor: | Intel Core i5-13500H |
CPU Cores / Threads: | 12 / 16 |
Core architecture: | hybrid (big.LITTLE) |
A-Core: | 4x Golden Cove |
B-Core: | 8x Gracemont |
Hyperthreading / SMT: | Yes |
Overclocking: | No |
A-Core Frequency: | 2.80 GHz (4.50 GHz) |
B-Core Frequency: | 1.80 GHz (3.30 GHz) |
GPU name: | Intel Iris Xe Graphics 80 (Alder Lake) |
GPU frequency: | 0.40 GHz |
GPU (Turbo): | 1.30 GHz |
Execution units: | 80 |
Shader: | 640 |
Max. GPU Memory: | 32 GB |
Max. displays: | 4 |
Generation: | 13 |
Direct X: | 12.1 |
Technology: | 10 nm |
Release date: | Q1/2022 |
h265 / HEVC (8 bit): | Decode / Encode |
h265 / HEVC (10 bit): | Decode / Encode |
h264: | Decode / Encode |
VP8: | Decode |
VP9: | Decode / Encode |
AV1: | Decode |
AVC: | Decode / Encode |
VC-1: | Decode |
JPEG: | Decode / Encode |
Memory & PCIeThe processor can use up to 64 GB memory in 2 (Dual Channel) memory channels. The maximum memory bandwidth is 76.8 GB/s. The memory type as well as the amount of memory can greatly affect the speed of the system. |
|
Memory type: | DDR4-3200 DDR5-4800 LPDDR4X-4266 LPDDR5-5200 |
Max. Memory: | 64 GB |
Memory channels: | 2 (Dual Channel) |
Bandwidth: | 76.8 GB/s |
ECC: | No |
PCIe: | 4.0 x 28 |
AES-NI: | Yes |
Thermal ManagementThe thermal design power (TDP for short) of the processor is 45 W. The TDP specifies the necessary cooling solution that is required to cool the processor sufficiently. The TDP usually gives a rough idea of the actual power consumption of the CPU. |
|
TDP (PL1 / PBP): | 45 W |
TDP (PL2): | 115 W |
TDP up: | -- |
TDP down: | -- |
Tjunction max.: | 100 °C |
Technology: | 10 nm |
Chip design: | Monolithic |
Socket: | BGA 1744 |
L2-Cache: | 9.00 MB |
L3-Cache: | 18.00 MB |
Architecture: | Alder Lake H |
Operating systems: | Windows 10, Windows 11, Linux |
Virtualization: | VT-x, VT-x EPT, VT-d |
Instruction set (ISA): | x86-64 (64 bit) |
ISA extensions: | SSE4.1, SSE4.2, AVX2, AVX2+ |
Release date: | Q1/2022 |
Release price: | 311 $ |
Part Number: | -- |
Documents: | -- |
![]() |
