Name: | Intel Celeron N4100 |
---|---|
Family: | Intel Celeron |
CPU group: | Intel Celeron J4000/N4000/N5000 |
Architecture: | Gemini Lake |
Segment: | Mobile |
Generation: | 9 |
Predecessor: | -- |
Successor: | Intel Celeron N5100 |
CPU Cores / Threads: | 4 / 4 |
---|---|
Core architecture: | normal |
Cores: | 4x |
Hyperthreading / SMT: | No |
---|---|
Overclocking: | No |
Frequency: | 1.10 GHz |
Turbo Frequency (1 Core): | 2.40 GHz |
Turbo Frequency (4 Cores): | 2.40 GHz |
GPU name: | Intel UHD Graphics 600 |
---|---|
GPU frequency: | 0.20 GHz |
GPU (Turbo): | 0.70 GHz |
Compute units: | 12 |
Shader: | 96 |
Max. GPU Memory: | 8 GB |
Max. displays: | 3 |
---|---|
Generation: | 9.5 |
Direct X: | 12 |
Technology: | 14 nm |
Release date: | Q4/2017 |
h265 / HEVC (8 bit): | Decode / Encode |
---|---|
h265 / HEVC (10 bit): | Decode / Encode |
h264: | Decode / Encode |
VP8: | Decode / Encode |
VP9: | Decode / Encode |
AV1: | No |
---|---|
AVC: | Decode / Encode |
VC-1: | Decode |
JPEG: | Decode / Encode |
Memory & PCIeThe Intel Celeron N4100 supports up to 8 GB memory in up to 2 (Dual Channel) memory channels. This results in a maximum memory bandwidth of 38.4 GB/s. |
|
Memory type: | Memory bandwidth: |
---|---|
LPDDR4-2400 DDR4-2400 | 38.4 GB/s 38.4 GB/s |
Max. Memory: | 8 GB |
Memory channels: | 2 (Dual Channel) |
ECC: | No |
PCIe: | 2.0 x 6 |
PCIe Bandwidth: | 3.0 GB/s |
Thermal ManagementWith the TDP, the processor manufacturer specifies the cooling solution required for the processor. The Intel Celeron N4100 has a TDP of 6 W. |
|
---|---|
TDP (PL1 / PBP): | 6 W |
TDP (PL2): | -- |
TDP up: | -- |
TDP down: | 4.8 W |
Tjunction max.: | 105 °C |
Technology: | 14 nm |
---|---|
Chip design: | Monolithic |
Socket: | BGA 1090 |
L2-Cache: | -- |
L3-Cache: | 4.00 MB |
AES-NI: | Yes |
Operating systems: | Windows 10, Windows 11, Linux |
Virtualization: | VT-x, VT-x EPT, VT-d |
---|---|
Instruction set (ISA): | x86-64 (64 bit) |
ISA extensions: | SSE4.1, SSE4.2 |
Release date: | Q4/2017 |
Release price: | -- |
Part Number: | -- |
Documents: | Technical data sheet |
![]() |
