Name: | AMD Ryzen 9 7945HX3D |
---|---|
Familie: | AMD Ryzen 9 (45) |
CPU Gruppe: | AMD Ryzen 7045 (6) |
Architektur: | Dragon Range (Zen 4) |
Technologie: | 5 nm |
Segment: | Notebook |
Generation: | 6 |
Vorgänger: | -- |
Nachfolger: | -- |
CPU Kerne / Threads: | 16 / 32 |
---|---|
Kernarchitektur: | normal |
Kerne: | 16x Zen 4 |
Hyperthreading / SMT: | Ja |
---|---|
Übertaktung: | Nein |
Taktfrequenz: | 2,30 GHz |
Turbo Taktfrequenz (1 Kern): | 5,40 GHz |
Turbo Taktfrequenz (16 Kerne): | -- |
GPU Name: | AMD Radeon 610M |
---|---|
Grafik-Taktfrequenz: | 0,40 GHz |
GPU (Turbo): | 2,20 GHz |
Ausführungseinheiten: | 2 |
Shader: | 128 |
Hardware Raytracing: | Ja |
Erscheinungsdatum: | Q3/2022 |
Max. Bildschirme: | 3 |
---|---|
Generation: | 9 |
Direct X: | 12 |
Technologie: | 6 nm |
Max. GPU Speicher: | 8 GB |
Frame Generation: | Nein |
h265 / HEVC (8 bit): | Dekodieren / Enkodieren |
---|---|
h265 / HEVC (10 bit): | Dekodieren / Enkodieren |
h264: | Dekodieren / Enkodieren |
VP8: | Dekodieren / Enkodieren |
VP9: | Dekodieren / Enkodieren |
AV1: | Dekodieren |
---|---|
AVC: | Dekodieren / Enkodieren |
VC-1: | Dekodieren |
JPEG: | Dekodieren / Enkodieren |
Arbeitsspeicher & PCIeBis zu 64 GB Arbeitsspeicher kann der Prozessor in 2 (Dual Channel) Speicherkanälen nutzen. Die maximale Speicherbandbreite liegt bei 83,2 GB/s. Der Arbeitsspeichertyp sowie die Menge des Arbeitsspeichers kann die Geschwindigkeit des Systems stark beeinflussen. |
|
Speichertyp: | Speicherbandbreite: |
---|---|
DDR5-5200 | 83,2 GB/s |
Max. Speicher: | 64 GB |
Speicherkanäle: | 2 (Dual Channel) |
ECC: | Nein |
PCIe: | 5.0 x 28 |
PCIe Bandbreite: | 110,3 GB/s |
LeistungsaufnahmeDie Thermal Design Power (kurz TDP) des Prozessors liegt bei 55 W. Die TDP gibt die notwendige Kühllösung vor, die benötigt wird um den Prozessor ausreichend zu kühlen. Die TDP gibt in der Regel einen groben Einblick auf den tatsächlichen Energieverbrauch der CPU. |
|
---|---|
TDP (PL1 / PBP): | 55 W |
TDP (PL2): | -- |
TDP up: | 75 W |
TDP down: | -- |
Tjunction max.: | 89 °C |
Technologie: | 5 nm |
---|---|
Chip-Design: | Chiplet |
Sockel: | FL1 |
L2-Cache: | 16,00 MB |
L3-Cache: | 128,00 MB |
AES-NI: | Ja |
Betriebssysteme: | Windows 10, Windows 11, Linux |
Virtualisierung: | AMD-V, SVM |
---|---|
Befehlssatz (ISA): | x86-64 (64 bit) |
ISA Erweiterungen: | SSE4a, SSE4.1, SSE4.2,FMA3, AVX2, AVX512 |
Erscheinungsdatum: | Q3/2023 |
Erscheinungspreis: | -- |
Artikelnummer: | 100-000001086 |
Dokumente: | Technisches Datenblatt |
