CPU lineageThe segment in which we have classified the Intel Core i3-1110G4. Here you can see if it is a desktop processor or a mobile processor or which processor may be the successor of the Intel Core i3-1110G4. |
|
Name: | Intel Core i3-1110G4 |
Family: | Intel Core i3 |
CPU group: | Intel Core i 1100G/11000U |
Segment: | Mobile |
Generation: | 11 |
Predecessor: | -- |
Successor: | -- |
CPU Cores / Threads: | 2 / 4 |
Core architecture: | normal |
Cores: | 2x |
Hyperthreading / SMT: | Yes |
Overclocking: | No |
Frequency: | 1.10 GHz |
Turbo Frequency (1 Core): | 3.50 GHz |
Turbo Frequency (2 Cores): | 3.00 GHz |
GPU name: | Intel UHD Graphics (Tiger Lake G4) |
GPU frequency: | 0.30 GHz |
GPU (Turbo): | 1.10 GHz |
Execution units: | 48 |
Shader: | 384 |
Max. GPU Memory: | 32 GB |
Max. displays: | 4 |
Generation: | 11 |
Direct X: | 12 |
Technology: | 10 nm |
Release date: | Q3/2020 |
h265 / HEVC (8 bit): | Decode / Encode |
h265 / HEVC (10 bit): | Decode / Encode |
h264: | Decode / Encode |
VP8: | Decode |
VP9: | Decode |
AV1: | No |
AVC: | Decode |
VC-1: | Decode |
JPEG: | Decode / Encode |
Memory & PCIeThe processor can use up to 32 GB memory in 2 (Dual Channel) memory channels. The maximum memory bandwidth is 34.1 GB/s. The memory type as well as the amount of memory can greatly affect the speed of the system. |
|
Memory type: | LPDDR4X-4266 |
Max. Memory: | 32 GB |
Memory channels: | 2 (Dual Channel) |
Bandwidth: | 34.1 GB/s |
ECC: | No |
PCIe: | 4.0 x 4 |
AES-NI: | Yes |
Thermal ManagementThe thermal design power (TDP for short) of the processor is 15 W. The TDP specifies the necessary cooling solution that is required to cool the processor sufficiently. The TDP usually gives a rough idea of the actual power consumption of the CPU. |
|
TDP (PL1 / PBP): | 15 W |
TDP (PL2): | -- |
TDP up: | -- |
TDP down: | 7 W |
Tjunction max.: | 100 °C |
Technology: | 10 nm |
Chip design: | Monolithic |
Socket: | BGA 1526 |
L2-Cache: | -- |
L3-Cache: | 8.00 MB |
Architecture: | Tiger Lake U |
Operating systems: | Windows 10, Windows 11, Linux |
Virtualization: | VT-x, VT-x EPT, VT-d |
Instruction set (ISA): | x86-64 (64 bit) |
ISA extensions: | SSE4.1, SSE4.2, AVX2, AVX-512 |
Release date: | Q1/2021 |
Release price: | 309 $ |
Part Number: | -- |
Documents: | Technical data sheet |
![]() |
