Name: | Intel Core i7-13700HX |
---|---|
Family: | Intel Core i7 |
CPU group: | Intel Core i 13000H |
Architecture: | Raptor Lake H |
Segment: | Mobile |
Generation: | 13 |
Predecessor: | -- |
Successor: | -- |
CPU Cores / Threads: | 16 / 24 |
---|---|
Core architecture: | hybrid (big.LITTLE) |
A-Core: | 8x Raptor Cove |
B-Core: | 8x Gracemont |
Hyperthreading / SMT: | Yes |
---|---|
Overclocking: | No |
A-Core Frequency: | 2.10 GHz (5.00 GHz) |
B-Core Frequency: | 1.50 GHz (3.70 GHz) |
GPU name: | Intel UHD Graphics 13th Gen (32 EU) |
---|---|
GPU frequency: | 0.40 GHz |
GPU (Turbo): | 1.55 GHz |
Compute units: | 32 |
Shader: | 256 |
Max. GPU Memory: | 64 GB |
Max. displays: | 3 |
---|---|
Generation: | 13 |
Direct X: | 12 |
Technology: | 10 nm |
Release date: | Q1/2023 |
h265 / HEVC (8 bit): | Decode / Encode |
---|---|
h265 / HEVC (10 bit): | Decode / Encode |
h264: | Decode / Encode |
VP8: | Decode / Encode |
VP9: | Decode / Encode |
AV1: | Decode |
---|---|
AVC: | Decode / Encode |
VC-1: | Decode |
JPEG: | Decode / Encode |
Memory & PCIeThe Intel Core i7-13700HX supports a maximum of 128 GB memory. Depending on the mainboard, the processor can use a maximum of 2 (Dual Channel) memory channels. This results in a maximum bandwidth of the main memory of 76.8 GB/s. |
|
Memory type: | Memory bandwidth: |
---|---|
DDR5-4800 DDR4-3200 | 76.8 GB/s 51.2 GB/s |
Max. Memory: | 128 GB |
Memory channels: | 2 (Dual Channel) |
ECC: | Yes |
PCIe: | 5.0 x 20 |
PCIe Bandwidth: | 78.8 GB/s |
Thermal ManagementThe Intel Core i7-13700HX has a TDP of 55 W. Based on the TDP, the system manufacturer can and must adapt the cooling solution to the processor. |
|
---|---|
TDP (PL1 / PBP): | 55 W |
TDP (PL2): | 157 W |
TDP up: | 86 W |
TDP down: | 45 W |
Tjunction max.: | 100 °C |
Technology: | 10 nm |
---|---|
Chip design: | Monolithic |
Socket: | BGA 1744 |
L2-Cache: | 24.00 MB |
L3-Cache: | 30.00 MB |
AES-NI: | Yes |
Operating systems: | Windows 10, Windows 11, Linux |
Virtualization: | VT-x, VT-x EPT, VT-d |
---|---|
Instruction set (ISA): | x86-64 (64 bit) |
ISA extensions: | SSE4.1, SSE4.2, AVX2, AVX2+ |
Release date: | Q1/2023 |
Release price: | 500 $ |
Part Number: | -- |
Documents: | Technical data sheet |
![]() |
