Intel Core i3-8100T Benchmark, Test and specs

Last updated:
The Intel Core i3-8100T has 4 cores with 4 threads and is based on the 8. gen of the Intel Core i3 series. The processor uses a mainboard with the LGA 1151-2 socket and was released in Q2/2018.
Intel Core i3-8100T

CPU lineage

The segment in which we have classified the Intel Core i3-8100T. Here you can see if it is a desktop processor or a mobile processor or which processor may be the successor of the Intel Core i3-8100T.

Name: Intel Core i3-8100T
Family: Intel Core i3
CPU group: Intel Core i 8000
Segment: Desktop / Server
Generation: 8
Predecessor: Intel Core i3-7100T
Successor: Intel Core i3-9100T

CPU Cores and Base Frequency

In addition to the number of CPU cores and threads, you can see here whether the Intel Core i3-8100T can be overclocked. You will also find the clock frequencies of the processor (single-core and multi-core) here. The number of CPU cores greatly affects the speed of the processor.

CPU Cores / Threads: 4 / 4
Core architecture: normal
Cores: 4x
Hyperthreading / SMT: No
Overclocking: No
Frequency: 3.10 GHz
Turbo Frequency (1 Core): --
Turbo Frequency (4 Cores): --

Internal Graphics

The Intel Core i3-8100T has integrated graphics, called iGPU for short. The iGPU uses the system's main memory as graphics memory and sits on the processor's die. A processor with integrated graphics is also called APU (Accelerated Processing Unit).

GPU name: Intel UHD Graphics 630
GPU frequency: 0.35 GHz
GPU (Turbo): 1.10 GHz
Execution units: 24
Shader: 192
Max. GPU Memory: 64 GB
Max. displays: 3
Generation: 9.5
Direct X: 12
Technology: 14 nm
Release date: Q4/2017

Hardware codec support

A photo or video codec that is accelerated in hardware can greatly accelerate the working speed of a processor and extend the battery life of notebooks or smartphones when playing videos.

h265 / HEVC (8 bit): Decode / Encode
h265 / HEVC (10 bit): Decode / Encode
h264: Decode / Encode
VP8: Decode / Encode
VP9: Decode / Encode
AV1: No
AVC: Decode / Encode
VC-1: Decode
JPEG: Decode / Encode

Memory & PCIe

The memory type as well as the amount of memory can greatly affect the speed of the processor. The memory bandwidth depends on several factors and is given in gigabytes per second.

Memory type: DDR4-2400
Max. Memory: 64 GB
Memory channels: 2
Bandwidth: --
ECC: Yes
PCIe: 3.0 x 16
AES-NI: Yes

Thermal Management

The Thermal Design Power (TDP for short) specifies the necessary cooling solution to cool the processor sufficiently. The TDP usually only gives a rough idea of the real consumption of a CPU.

TDP (PL1): 65 W
TDP (PL2): --
TDP up: --
TDP down: --
Tjunction max.: --

Technical details

Here you will find information on the size of the level 2 and level 3 cache of the Intel Core i3-8100T as well as a list of the processors ISA extensions. We have documented the architecture and the manufacturing technology for you as well as the release date.

Technology: 14 nm
Chip design: Monolithic
Socket: LGA 1151-2
L2-Cache: --
L3-Cache: 6.00 MB
Architecture: Coffee Lake S
Operating systems: Windows 10, Windows 11, Linux
Virtualization: VT-x, VT-x EPT, VT-d
Instruction set (ISA): x86-64 (64 bit)
ISA extensions: SSE4.1, SSE4.2, AVX2
Release date: Q2/2018
Release price: 125 $
Part Number: --
Documents: --

Benchmark results

Verified Benchmark results
The benchmark results for the Intel Core i3-8100T have been carefully checked by us. We only publish benchmark results that have been created by us or that have been submitted by a visitor and then checked by a team member. All results are based on and fullfill our benchmark guidelines.

Screenshots:

Cinebench R23 (Single-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

AMD Ryzen 7 2700U AMD Ryzen 7 2700U
4C 8T @ 3.80 GHz
823
AMD Ryzen 7 PRO 2700U AMD Ryzen 7 PRO 2700U
4C 8T @ 3.80 GHz
823
Intel Core i7-3770 Intel Core i7-3770
4C 8T @ 3.90 GHz
820
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
818
Intel Core i5-4590 Intel Core i5-4590
4C 4T @ 3.70 GHz
811
Intel Core i5-6500T Intel Core i5-6500T
4C 4T @ 3.10 GHz
809
Intel Core i5-7200U Intel Core i5-7200U
2C 4T @ 3.10 GHz
806
Show all Cinebench R23 (Single-Core) results



Cinebench R23 (Multi-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

Intel Core i7-10610U Intel Core i7-10610U
4C 8T @ 1.80 GHz
3267
Intel Core i7-4770HQ Intel Core i7-4770HQ
4C 8T @ 2.20 GHz
3249
AMD Ryzen 5 3450U AMD Ryzen 5 3450U
4C 8T @ 3.10 GHz
3197
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
3171
Intel Core i7-1160G7 Intel Core i7-1160G7
4C 8T @ 3.60 GHz
3167
Intel Core i5-4590 Intel Core i5-4590
4C 4T @ 3.50 GHz
3167
Intel Core i7-3615QM Intel Core i7-3615QM
4C 8T @ 2.30 GHz
3163
Show all Cinebench R23 (Multi-Core) results



Cinebench R20 (Single-Core)

Cinebench R20 is the successor of Cinebench R15 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

Intel Core i5-4590S Intel Core i5-4590S
4C 4T @ 3.70 GHz
321
Intel Core i5-8200Y Intel Core i5-8200Y
2C 4T @ 3.90 GHz
321
Intel Core i5-8310Y Intel Core i5-8310Y
2C 4T @ 3.90 GHz
321
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
320
Intel Core i5-4690T Intel Core i5-4690T
4C 4T @ 3.50 GHz
320
Intel Core i5-4590 Intel Core i5-4590
4C 4T @ 3.70 GHz
319
Intel Celeron G5900TE Intel Celeron G5900TE
2C 2T @ 3.00 GHz
318
Show all Cinebench R20 (Single-Core) results



Cinebench R20 (Multi-Core)

Cinebench R20 is the successor of Cinebench R15 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

Intel Core i7-4720HQ Intel Core i7-4720HQ
4C 8T @ 3.40 GHz
1279
AMD Ryzen 5 3450U AMD Ryzen 5 3450U
4C 8T @ 3.10 GHz
1246
Intel Core i5-4670 Intel Core i5-4670
4C 4T @ 3.60 GHz
1245
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
1231
Intel Core i7-3630QM Intel Core i7-3630QM
4C 8T @ 2.40 GHz
1230
Intel Core i5-4590 Intel Core i5-4590
4C 4T @ 3.50 GHz
1227
Intel Core i5-4590S Intel Core i5-4590S
4C 4T @ 3.30 GHz
1223
Show all Cinebench R20 (Multi-Core) results



Geekbench 5, 64bit (Single-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

AMD Ryzen 5 2600H AMD Ryzen 5 2600H
4C 8T @ 3.60 GHz
834
Intel Core i5-8305G Intel Core i5-8305G
4C 8T @ 3.80 GHz
834
Intel Core i7-5557U Intel Core i7-5557U
2C 4T @ 3.40 GHz
834
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
833
Intel Core i7-3770S Intel Core i7-3770S
4C 8T @ 3.90 GHz
831
Intel Core i3-4170 Intel Core i3-4170
2C 4T @ 3.70 GHz
830
Intel Core i5-6440HQ Intel Core i5-6440HQ
4C 4T @ 3.50 GHz
829
Show all Geekbench 5, 64bit (Single-Core) results



Geekbench 5, 64bit (Multi-Core)

Geekbench 5 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

Apple A12 Bionic Apple A12 Bionic
6C 6T @ 2.49 GHz
2731
Intel Core i5-7500T Intel Core i5-7500T
4C 4T @ 3.10 GHz
2718
Intel Core i5-6400 Intel Core i5-6400
4C 4T @ 3.00 GHz
2706
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
2700
Qualcomm Snapdragon 860 Qualcomm Snapdragon 860
8C 8T @ 2.42 GHz
2698
Intel Core i7-4701EQ Intel Core i7-4701EQ
4C 8T @ 3.00 GHz
2698
Intel Core i7-4700EQ Intel Core i7-4700EQ
4C 8T @ 3.00 GHz
2698
Show all Geekbench 5, 64bit (Multi-Core) results



iGPU - FP32 Performance (Single-precision GFLOPS)

The theoretical computing performance of the internal graphics unit of the processor with simple accuracy (32 bit) in GFLOPS. GFLOPS indicates how many billion floating point operations the iGPU can perform per second.

Intel Core i5-7500 Intel Core i5-7500
Intel HD Graphics 630 @ 1.10 GHz
422
Intel Core i5-7600T Intel Core i5-7600T
Intel HD Graphics 630 @ 1.10 GHz
422
Intel Core i7-6700T Intel Core i7-6700T
Intel HD Graphics 530 @ 1.10 GHz
422
Intel Core i3-8100T Intel Core i3-8100T
Intel UHD Graphics 630 @ 1.10 GHz
422
AMD Athlon Silver Pro 3125GE AMD Athlon Silver Pro 3125GE
AMD Radeon Vega 3 Graphics @ 1.10 GHz
422
AMD Athlon Gold Pro 3150G AMD Athlon Gold Pro 3150G
AMD Radeon Vega 3 Graphics @ 1.10 GHz
422
AMD Athlon Gold 3150GE AMD Athlon Gold 3150GE
AMD Radeon Vega 3 Graphics @ 1.10 GHz
422
Show all iGPU - FP32 Performance (Single-precision GFLOPS) results



Estimated results for PassMark CPU Mark

Some of the CPUs listed below have been benchmarked by CPU-monkey. However the majority of CPUs have not been tested and the results have been estimated by a CPU-monkey’s secret proprietary formula. As such they do not accurately reflect the actual Passmark CPU mark values and are not endorsed by PassMark Software Pty Ltd.

Intel Core i5-3570 Intel Core i5-3570
4C 4T @ 3.80 GHz
7025
AMD FX-6350 AMD FX-6350
6C 6T @ 4.20 GHz
7009
Intel Core i7-4770 Intel Core i7-4770
4C 8T @ 3.60 GHz
7005
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
6987
Intel Core i7-990X Intel Core i7-990X
6C 12T @ 3.46 GHz
6945
Intel Xeon E5-2609 v4 Intel Xeon E5-2609 v4
8C 8T @ 1.70 GHz
6925
Intel Xeon Bronze 3106 Intel Xeon Bronze 3106
8C 8T @ 1.70 GHz
6889
Show all Estimated results for PassMark CPU Mark results



Cinebench R15 (Single-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

Intel Core i5-4330M Intel Core i5-4330M
2C 4T @ 3.50 GHz
134
Intel Pentium G3450 Intel Pentium G3450
2C 2T @ 3.40 GHz
133
Intel Xeon E5-2660 v4 Intel Xeon E5-2660 v4
14C 28T @ 3.20 GHz
133
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
132
AMD Ryzen 5 2400GE AMD Ryzen 5 2400GE
4C 8T @ 3.50 GHz
132
Intel Core i5-8210Y Intel Core i5-8210Y
2C 4T @ 3.60 GHz
132
Intel Celeron G4900 Intel Celeron G4900
2C 2T @ 3.10 GHz
132
Show all Cinebench R15 (Single-Core) results



Cinebench R15 (Multi-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

Intel Core i5-4690 Intel Core i5-4690
4C 4T @ 3.70 GHz
534
Intel Core i5-4690K Intel Core i5-4690K
4C 4T @ 3.70 GHz
534
Intel Xeon E3-1240L v5 Intel Xeon E3-1240L v5
4C 8T @ 2.40 GHz
533
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
530
Intel Core i5-7500T Intel Core i5-7500T
4C 4T @ 3.10 GHz
528
Intel Core i5-6440EQ Intel Core i5-6440EQ
4C 4T @ 3.00 GHz
528
AMD Ryzen 5 3450U AMD Ryzen 5 3450U
4C 8T @ 3.10 GHz
527
Show all Cinebench R15 (Multi-Core) results



Geekbench 3, 64bit (Single-Core)

Geekbench 3 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

Intel Core i7-3960X Intel Core i7-3960X
6C 12T @ 3.90 GHz
3314
Intel Core i7-4800MQ Intel Core i7-4800MQ
4C 8T @ 3.70 GHz
3310
Intel Core i3-4160T Intel Core i3-4160T
2C 4T @ 3.10 GHz
3305
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
3302
Intel Core i5-3570K Intel Core i5-3570K
4C 4T @ 3.80 GHz
3300
Intel Core i5-3570 Intel Core i5-3570
4C 4T @ 3.80 GHz
3300
Intel Core i7-4610M Intel Core i7-4610M
2C 4T @ 3.60 GHz
3300
Show all Geekbench 3, 64bit (Single-Core) results



Geekbench 3, 64bit (Multi-Core)

Geekbench 3 is a cross plattform benchmark that heavily uses the systems memory. A fast memory will push the result a lot. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

AMD FX-8150 AMD FX-8150
8C 8T @ 4.20 GHz
10660
AMD Ryzen 3 1300X AMD Ryzen 3 1300X
4C 4T @ 3.60 GHz
10602
AMD Ryzen 3 PRO 1200 AMD Ryzen 3 PRO 1200
4C 4T @ 3.30 GHz
10531
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
10500
Intel Core i5-7500T Intel Core i5-7500T
4C 4T @ 3.10 GHz
10420
Intel Core i5-4570 Intel Core i5-4570
4C 4T @ 3.40 GHz
10420
Intel Core i5-6600T Intel Core i5-6600T
4C 4T @ 3.10 GHz
10383
Show all Geekbench 3, 64bit (Multi-Core) results



Cinebench R11.5, 64bit (Single-Core)

Cinebench 11.5 is based on the Cinema 4D Suite, a software that is popular to generate forms and other stuff in 3D. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

Intel Core i7-3770 Intel Core i7-3770
4C 8T @ 3.90 GHz
1.65
Intel Core i7-5850HQ Intel Core i7-5850HQ
4C 8T @ 3.60 GHz
1.65
Intel Xeon E5-2667 v2 Intel Xeon E5-2667 v2
8C 16T @ 4.00 GHz
1.65
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
1.64
Intel Xeon Gold 5118 Intel Xeon Gold 5118
12C 24T @ 3.20 GHz
1.64
Intel Xeon Gold 5119T Intel Xeon Gold 5119T
14C 28T @ 3.20 GHz
1.64
Intel Xeon Gold 5120 Intel Xeon Gold 5120
14C 28T @ 3.20 GHz
1.64
Show all Cinebench R11.5, 64bit (Single-Core) results



Cinebench R11.5, 64bit (Multi-Core)

Cinebench 11.5 is based on the Cinema 4D Suite, a software that is popular to generate forms and other stuff in 3D. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

Intel Xeon E3-1220 v3 Intel Xeon E3-1220 v3
4C 4T @ 3.50 GHz
5.67
Intel Xeon E3-1505L v5 Intel Xeon E3-1505L v5
4C 8T @ 2.40 GHz
5.66
AMD Phenom II X6 1090T AMD Phenom II X6 1090T
6C 6T @ 3.60 GHz
5.65
Intel Core i3-8100T Intel Core i3-8100T
4C 4T @ 3.10 GHz
5.64
Intel Core i5-3470 Intel Core i5-3470
4C 4T @ 3.60 GHz
5.62
Intel Core i5-7500T Intel Core i5-7500T
4C 4T @ 3.10 GHz
5.6
Intel Core i5-6600T Intel Core i5-6600T
4C 4T @ 3.10 GHz
5.59
Show all Cinebench R11.5, 64bit (Multi-Core) results



Cinebench R11.5, 64bit (iGPU, OpenGL)

Cinebench 11.5 is based on the Cinema 4D Suite, a software that is popular to generate forms and other stuff in 3D. The iGPU test uses the CPU internal graphic unit to execute OpenGL commands.

Intel Core i3-8100 Intel Core i3-8100
Intel UHD Graphics 630 @ 1.10 GHz
37.4
Intel Core i5-8305G Intel Core i5-8305G
AMD Radeon RX Vega M GL Graphics @ 1.01 GHz
37.4
Intel Core i7-8705G Intel Core i7-8705G
AMD Radeon RX Vega M GL Graphics @ 1.01 GHz
37.4
Intel Core i3-8100T Intel Core i3-8100T
Intel UHD Graphics 630 @ 1.10 GHz
37.4
Intel Core i3-7167U Intel Core i3-7167U
Intel Iris Plus Graphics 650 @ 1.00 GHz
37.2
Intel Core i3-7100U Intel Core i3-7100U
Intel HD Graphics 620 @ 1.00 GHz
37.2
AMD A8-3870K AMD A8-3870K
AMD Radeon HD 6550D @ 0.60 GHz
37
Show all Cinebench R11.5, 64bit (iGPU, OpenGL) results



Leaderboards

In our leaderboards, we have clearly compiled the best processors for specific categories for you. The leaderboards are always up to date and are regularly updated by us. The best processors are selected according to popularity and speed in benchmarks as well as the price-performance ratio.


Popular comparisons

1. Intel Core i3-8100T Intel Core i3-8100 Intel Core i3-8100T vs Intel Core i3-8100
2. Intel Core i3-8100T Intel Pentium Gold G5400T Intel Core i3-8100T vs Intel Pentium Gold G5400T
3. Intel Core i3-8100T Intel Core i3-9100T Intel Core i3-8100T vs Intel Core i3-9100T
4. Intel Core i3-8100T Intel Core i5-6500T Intel Core i3-8100T vs Intel Core i5-6500T
5. Intel Core i3-8100T Intel Celeron J4125 Intel Core i3-8100T vs Intel Celeron J4125
6. AMD Ryzen Embedded V1500B Intel Core i3-8100T AMD Ryzen Embedded V1500B vs Intel Core i3-8100T
7. Intel Core i5-8500T Intel Core i3-8100T Intel Core i5-8500T vs Intel Core i3-8100T
8. Intel Core i3-8100T Intel Core i5-8400T Intel Core i3-8100T vs Intel Core i5-8400T
9. Intel Core i3-8300T Intel Core i3-8100T Intel Core i3-8300T vs Intel Core i3-8100T
10. Intel Core i3-8109U Intel Core i3-8100T Intel Core i3-8109U vs Intel Core i3-8100T
11. Intel Core i3-7100 Intel Core i3-8100T Intel Core i3-7100 vs Intel Core i3-8100T
12. Intel Core i5-9500T Intel Core i3-8100T Intel Core i5-9500T vs Intel Core i3-8100T
13. Intel Core i3-8100T Intel Core i3-7100T Intel Core i3-8100T vs Intel Core i3-7100T
14. Intel Core i3-8100T Intel Pentium Gold G5600 Intel Core i3-8100T vs Intel Pentium Gold G5600
15. Intel Pentium Silver J5005 Intel Core i3-8100T Intel Pentium Silver J5005 vs Intel Core i3-8100T


back to index
