Intel Pentium 2117U Benchmark, Test and specs

Last updated:
The Intel Pentium 2117U has 2 cores with 2 threads and is based on the 4. gen of the Intel Pentium series. The processor uses a mainboard with the BGA 1023 socket and was released in Q3/2012.
Intel Pentium 2117U

CPU lineage

The segment in which we have classified the Intel Pentium 2117U. Here you can see if it is a desktop processor or a mobile processor or which processor may be the successor of the Intel Pentium 2117U.

Name: Intel Pentium 2117U
Family: Intel Pentium
CPU group: Intel Pentium 2000
Segment: Mobile
Generation: 4
Predecessor: --
Successor: --

CPU Cores and Base Frequency

In addition to the number of CPU cores and threads, you can see here whether the Intel Pentium 2117U can be overclocked. You will also find the clock frequencies of the processor (single-core and multi-core) here. The number of CPU cores greatly affects the speed of the processor.

CPU Cores / Threads: 2 / 2
Core architecture: normal
Cores: 2x
Hyperthreading / SMT: No
Overclocking: No
Frequency: 1.80 GHz
Turbo Frequency (1 Core): --
Turbo Frequency (2 Cores): --

Internal Graphics

The Intel Pentium 2117U has integrated graphics, called iGPU for short. The iGPU uses the system's main memory as graphics memory and sits on the processor's die. A processor with integrated graphics is also called APU (Accelerated Processing Unit).

GPU name: Intel HD Graphics (Ivy Bridge GT1)
GPU frequency: 0.35 GHz
GPU (Turbo): 1.00 GHz
Execution units: 6
Shader: 48
Max. GPU Memory: 2 GB
Max. displays: 3
Generation: 7
Direct X: 11.0
Technology: 22 nm
Release date: Q4/2012

Hardware codec support

A photo or video codec that is accelerated in hardware can greatly accelerate the working speed of a processor and extend the battery life of notebooks or smartphones when playing videos.

h265 / HEVC (8 bit): No
h265 / HEVC (10 bit): No
h264: Decode / Encode
VP8: No
VP9: No
AV1: No
AVC: Decode / Encode
VC-1: Decode
JPEG: Decode

Memory & PCIe

The memory type as well as the amount of memory can greatly affect the speed of the processor. The memory bandwidth depends on several factors and is given in gigabytes per second.

Memory type: DDR3-1333
DDR3-1600
DDR3L-1333 SO-DIMM
DDR3L-1600 SO-DIMM
Max. Memory: 32 GB
Memory channels: 2 (Dual Channel)
Bandwidth: --
ECC: No
PCIe: 2.0 x 16
AES-NI: Yes

Thermal Management

The Thermal Design Power (TDP for short) specifies the necessary cooling solution to cool the processor sufficiently. The TDP usually only gives a rough idea of the real consumption of a CPU.

TDP (PL1 / PBP): 17 W
TDP (PL2): --
TDP up: --
TDP down: --
Tjunction max.: 90 °C

Technical details

Here you will find information on the size of the level 2 and level 3 cache of the Intel Pentium 2117U as well as a list of the processors ISA extensions. We have documented the architecture and the manufacturing technology for you as well as the release date.

Technology: 22 nm
Chip design: Monolithic
Socket: BGA 1023
L2-Cache: --
L3-Cache: 2.00 MB
Architecture: Ivy Bridge U
Operating systems: Windows 10, Linux
Virtualization: VT-x, VT-x EPT, VT-d
Instruction set (ISA): x86-64 (64 bit)
ISA extensions: SSE4.1, SSE4.2
Release date: Q3/2012
Release price: --
Part Number: --
Documents: --

Benchmark results

Verified Benchmark results
The benchmark results for the Intel Pentium 2117U have been carefully checked by us. We only publish benchmark results that have been created by us or that have been submitted by a visitor and then checked by a team member. All results are based on and fullfill our benchmark guidelines.

Screenshots:

Cinebench R23 (Single-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

AMD Athlon II X4 630 AMD Athlon II X4 630
4C 4T @ 2.80 GHz
363
AMD Athlon II X4 620e AMD Athlon II X4 620e
4C 4T @ 2.60 GHz
340
AMD Athlon II X4 620 AMD Athlon II X4 620
4C 4T @ 2.60 GHz
337
Intel Pentium 2117U Intel Pentium 2117U
2C 2T @ 1.80 GHz
331
AMD Athlon II X4 615e AMD Athlon II X4 615e
4C 4T @ 2.50 GHz
327
Intel Core2 Duo E6600 Intel Core2 Duo E6600
2C 2T @ 2.40 GHz
314
AMD Athlon II X4 610e AMD Athlon II X4 610e
4C 4T @ 2.40 GHz
314
Show all Cinebench R23 (Single-Core) results



Cinebench R23 (Multi-Core)

Cinebench R23 is the successor of Cinebench R20 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

Intel Core i7-4650U Intel Core i7-4650U
2C 4T @ 2.90 GHz
902
Intel Celeron N4500 Intel Celeron N4500
2C 2T @ 2.40 GHz
723
Intel Core m3-7Y30 Intel Core m3-7Y30
2C 4T @ 2.00 GHz
645
Intel Pentium 2117U Intel Pentium 2117U
2C 2T @ 1.80 GHz
612
Intel Core2 Duo E6600 Intel Core2 Duo E6600
2C 2T @ 2.40 GHz
579
AMD Athlon II X2 270u AMD Athlon II X2 270u
2C 2T @ 2.00 GHz
531
AMD Athlon II X2 260u AMD Athlon II X2 260u
2C 2T @ 1.80 GHz
478
Show all Cinebench R23 (Multi-Core) results



iGPU - FP32 Performance (Single-precision GFLOPS)

The theoretical computing performance of the internal graphics unit of the processor with simple accuracy (32 bit) in GFLOPS. GFLOPS indicates how many billion floating point operations the iGPU can perform per second.

Intel Celeron G1610 Intel Celeron G1610
Intel HD Graphics (Ivy Bridge GT1) @ 1.05 GHz
101
Intel Pentium G2020 Intel Pentium G2020
Intel HD Graphics (Ivy Bridge GT1) @ 1.05 GHz
101
MediaTek Helio P70 MediaTek Helio P70
ARM Mali-G72 MP3 @ 0.90 GHz
100
Intel Pentium 2117U Intel Pentium 2117U
Intel HD Graphics (Ivy Bridge GT1) @ 1.00 GHz
96
UNISOC Tiger T616 UNISOC Tiger T616
ARM Mali-G57 MP1 @ 0.75 GHz
96
Intel Pentium 997 Intel Pentium 997
Intel HD Graphics (Sandy Bridge GT1) @ 1.00 GHz
96
Intel Pentium 987 Intel Pentium 987
Intel HD Graphics (Sandy Bridge GT1) @ 1.00 GHz
96
Show all iGPU - FP32 Performance (Single-precision GFLOPS) results



CPU-Z Benchmark 17 (Multi-Core)

The CPU-Z benchmark measures a processor's performance by measuring the time it takes the system to complete all benchmark calculations. The faster the benchmark is completed, the higher the score.

AMD A4-6300 AMD A4-6300
2C 2T @ 3.70 GHz
355
AMD A4-5000 AMD A4-5000
4C 4T @ 1.50 GHz
354
Intel Celeron 3205U Intel Celeron 3205U
2C 2T @ 1.50 GHz
348
Intel Pentium 2117U Intel Pentium 2117U
2C 2T @ 1.80 GHz
347
Intel Core2 Duo E4500 Intel Core2 Duo E4500
2C 2T @ 2.20 GHz
346
Intel Pentium 3558U Intel Pentium 3558U
2C 2T @ 1.70 GHz
346
Intel Celeron 1000M Intel Celeron 1000M
2C 2T @ 1.80 GHz
346
Show all CPU-Z Benchmark 17 (Multi-Core) results



Cinebench R15 (Single-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The single-core test only uses one CPU core, the amount of cores or hyperthreading ability doesn't count.

AMD Athlon II X4 620 AMD Athlon II X4 620
4C 4T @ 2.60 GHz
62
AMD Athlon II X4 620e AMD Athlon II X4 620e
4C 4T @ 2.60 GHz
62
Intel Xeon E5-2603 v3 Intel Xeon E5-2603 v3
6C 6T @ 1.60 GHz
62
Intel Pentium 2117U Intel Pentium 2117U
2C 2T @ 1.80 GHz
61
Intel Core i3-4012Y Intel Core i3-4012Y
2C 4T @ 1.50 GHz
61
AMD A8-7650K AMD A8-7650K
4C 4T @ 3.80 GHz
61
Intel Celeron 3205U Intel Celeron 3205U
2C 2T @ 1.50 GHz
61
Show all Cinebench R15 (Single-Core) results



Cinebench R15 (Multi-Core)

Cinebench R15 is the successor of Cinebench 11.5 and is also based on the Cinema 4 Suite. Cinema 4 is a worldwide used software to create 3D forms. The multi-core test involves all CPU cores and taks a big advantage of hyperthreading.

Intel Celeron 3205U Intel Celeron 3205U
2C 2T @ 1.50 GHz
117
AMD A4-4000 AMD A4-4000
2C 2T @ 3.20 GHz
116
Intel Atom x5-Z8350 Intel Atom x5-Z8350
4C 4T @ 1.92 GHz
116
Intel Pentium 2117U Intel Pentium 2117U
2C 2T @ 1.80 GHz
115
Intel Core i3-4010Y Intel Core i3-4010Y
2C 4T @ 1.30 GHz
114
Intel Core2 Duo E6600 Intel Core2 Duo E6600
2C 2T @ 2.40 GHz
113
Intel Celeron N2930 Intel Celeron N2930
4C 4T @ 2.16 GHz
113
Show all Cinebench R15 (Multi-Core) results
