Name: | Intel Core i7-920 |
---|---|
Family: | Intel Core i7 |
CPU group: | Intel Core i7 900 |
Architecture: | Bloomfield |
Segment: | Desktop / Server |
Generation: | 1 |
Predecessor: | -- |
Successor: | -- |
CPU Cores / Threads: | 4 / 8 |
---|---|
Core architecture: | normal |
Cores: | 4x |
Hyperthreading / SMT: | Yes |
---|---|
Overclocking: | No |
Frequency: | 2.66 GHz |
Turbo Frequency (1 Core): | 2.93 GHz |
Turbo Frequency (4 Cores): | -- |
Memory & PCIeThe Intel Core i7-920 supports a maximum of 24 GB memory. Depending on the mainboard, the processor can use a maximum of 3 memory channels. This results in a maximum bandwidth of the main memory of 25.6 GB/s. |
|
Memory type: | Memory bandwidth: |
---|---|
DDR3-1066 | 25.6 GB/s |
Max. Memory: | 24 GB |
Memory channels: | 3 |
ECC: | No |
PCIe: | |
PCIe Bandwidth: | -- |
Thermal ManagementThe Intel Core i7-920 has a TDP of 130 W. Based on the TDP, the system manufacturer can and must adapt the cooling solution to the processor. |
|
---|---|
TDP (PL1 / PBP): | 130 W |
TDP (PL2): | -- |
TDP up: | -- |
TDP down: | -- |
Tjunction max.: | -- |
Technology: | 45 nm |
---|---|
Chip design: | Monolithic |
Socket: | LGA 1366 |
L2-Cache: | 1.00 MB |
L3-Cache: | 8.00 MB |
AES-NI: | No |
Operating systems: | Windows 10, Linux |
Virtualization: | VT-x, VT-x EPT |
---|---|
Instruction set (ISA): | x86-64 (64 bit) |
ISA extensions: | SSE4.1, SSE4.2 |
Release date: | Q4/2008 |
Release price: | 305 $ |
Part Number: | BX80601920 |
Documents: | Technical data sheet |
![]() |
